3M 7000140669

3M Scotchlok Copper Two Hole Long Barrel Lug 31100 Series

Page Loading...
3M Products
3M Scotchlok Copper Two Hole Long Barrel Lug 31100 Series

Mouse over image to zoom, click to enlarge

Description:
3M Scotchlok Copper Two Hole Long Barrel Lug 31100 Series

UPC:  05113852497

Part Number: 7000140669;31125

UNSPSC: 27121707

Status:  UNKNOWN

Retail Price:  $15.95 / EA
Your Price:  $11.70 / EA


Quantity  EA

Specifications

Manufacturer Name 3M Products
MfgPartNo 7000140669
Additional Information Inside Diameter 0.31 Inch; Outside Diameter 0.42 Inch; Used On Copper Conductor; Application Indoor, Outdoor; Operating Temperature 105 Deg C
Application Copper Conductor Only
Approval UL
Barrel Length 1.25 Inch
Barrel Type Long
Base Price 0.0000
Capacity 2
Catalog Number 31125
Color Brown
Commerce Sector Construction Materials
Commodity Code 64120
Commodity Description Large Terminals & Connectors
Conductor Material Copper
Conductor Size 2 AWG
CountryOfOrigin CL
DDCATEGORY 597
Directory CIS
Families 597
Family Description Large Terminals & Connectors
Image Location * Image
Industry ELX
InvoiceDescription 3M Scotchlok Copper Two Hole Long Barrel Lug 31100 Series;2-HOLE LNG-BARREL COP LUG
Item Number 52497
Length 4.85 Inch
Long Description COMPRESSION LUG, TIN PLATED COPPER MATERIAL; BROWN COLOR; 4.85 INCH OVERALL LENGTH; 1.25 INCH BARREL LENGTH; COPPER CONDUCTOR MATERIAL; UL APPROVAL; 35 KV VOLTAGE RATING; 2 AWG CONDUCTOR SIZE; 1/2 INCH STUD SIZE; 3 INCH L X 0.63 INCH W PAD SIZE
MSDS Form Number *
Material Tin Plated Copper
Model 31000
Noun *
Number Of Pad Holes 2
Overall Length 4.85 Inch
Pad Hole Spacing 1.75 Inch
Pad Size 3 Inch L x 0.63 Inch W
Product Description 3M Scotchlok Copper Two Hole Long Barrel Lug 31100 Series
Product Keywords WEBREADY
Product Name Crimp connectors
ProductLine 3M
Standard UL LISTED
Stud Size 1/2 Inch
Type Long Barrel
UNSPSC 27121707
UPC 05113852497
Vendor Name 3M ELECTRICAL MARKET TELECOMMUNICATIONS & SAFETY
Vendor Number 051138
Vendor Short Name 3M
Voltage Rating 35 KV

Resources

CatalogNumber 7000140669;31125
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
