| Manufacturer Name | APPLETON ELECTRIC CO. |
| MfgPartNo | BC400-M |
| Access Opening | Side |
| Additional Information | Wire Size (3) 1000 MCM; Capacity 1010 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC/CEC, NEMA FB-1 |
| Application | For Use With Rigid Metal Conduit And IMC |
| Approval | UL 514B, CSA C22.2 |
| Brand Name | Unilets[R] |
| Catalog Number | BC400-M |
| Commerce Sector | Construction Materials |
| Commodity Code | 25110 |
| Commodity Description | Steel Conduit Bodies & Covers |
| Configuration | C |
| Connection | Tapered Female Threaded |
| CountryOfOrigin | MX |
| DDCATEGORY | 549 |
| Directory | CIS |
| Families | 549 |
| Family Description | Steel Conduit Bodies & Covers |
| Finish | Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat) |
| Height | 7.56 in |
| Hub Location | Straight |
| Hub Size | 4;4 Inch |
| Image Location | * Image |
| Industry | ELX |
| Installation | Threaded |
| InvoiceDescription | 4 MOGUL UNILET TYPE C;4IN MALL C MOGUL UNILET |
| Item Number | 47418 |
| Length | 35.38 in |
| Long Description | RIGID CONDUIT OUTLET BODY AND COVER, ZINC ELECTROPLATED/CHROMATE/EPOXY POWDER COATED MALLEABLE IRON (BODY), STAINLESS STEEL (SCREW) MATERIAL; 35.38 INCH LENGTH X 5.63 INCH WIDTH X 7.56 INCH HEIGHT SIZE; IMC/THREADED RIGID METAL CONDUIT USED ON |
| MSDS Form Number | * |
| Material | Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw) |
| Material Quality | Malleable Iron |
| Noun | * |
| Number Of Hubs | 2 |
| Product Description | 4IN MALL C MOGUL UNILET |
| Product Keywords | WEBREADY |
| Product Name | Electrical conduit fitting body |
| ProductLine | APP |
| Size | 35.38 Inch Length x 5.63 Inch Width x 7.56 Inch Height |
| Special Features | Accurately tapped, tapered threads for tight, rigid joints and ground continuity;Covers have captive stainless steel screws to speed installation, prevent freezing of screws;Exclusive built-in rollers facilitate cable pulling;Larger body size facilitates pulling of large and heavy conductors;Length Requirement: distance between centerline of each hub bushing (conduit stop) exceeds eight times the trade diameter of the conduit per NEC 314.28(A)(1);Smooth, rounded integral bushing in each hub protects conductor insulation;Specially designed raised cast covers provide additional wiring area;Wiring capacity: 1010 CU-IN |
| Standard | UL 514B, UL File Number E2527, CSA C22.2 No. 18.3, CSA 065183, NEMA FB-1 |
| Type | Type C NEC 8X Conduit Outlet Body With Assembled Cover And Gasket |
| UNSPSC | 39131708 |
| UPC | 78138147418 |
| Used On | IMC/Threaded Rigid Metal Conduit |
| Vendor Name | APPLETON ELECTRIC COMPANY |
| Vendor Number | 781381 |
| Vendor Short Name | APP |
| Width | 5.63 in |
