| Manufacturer Name | APPLETON ELECTRIC CO. |
| MfgPartNo | ECP-20232 |
| Additional Information | Overall Dimension 1.75 Inch Width x 1.52 Inch Depth; Constructional Feature Explosionproof, Dust-Ignitionproof; Application Refinery, Petrochemical Plant and Other Areas Subject to Where Ignitable Gases are Present |
| Amperage Rating | 20 A |
| Application | Fits Any Standard Non-Explosionproof Receptacle as well as U-Line Explosionproof Receptacles |
| Approval | CSA |
| Base Price | 0.0000 |
| Brand Name | Appleton;U-Line |
| Catalog Number | ECP-20232 |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| CountryOfOrigin | MX |
| Current Rating | 20 Amp |
| DDCATEGORY | 574 |
| Directory | CIS |
| Enclosure | Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group F G, Class III, NEMA 3/3R/7BCD/9FG |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | ECP PLUG 20A 250V 2W3P;2W-3P PLUG |
| Item Number | 10587 |
| Long Description | POWER CONNECTOR, COPPER-FREE ALUMINUM MATERIAL; 0.538 INCH MIN. CABLE OUTER DIAMETER; 0.639 INCH MAX. CABLE OUTER DIAMETER; 2 WIRE(S); CSA APPROVAL; 250 VOLT AC VOLTAGE RATING |
| MSDS Form Number | * |
| Material | Copperfree (Less Than 4/10 Of 1 PCT) Aluminum;Copper-Free Aluminum |
| Mating Receptacle | Standard Non-Explosionproof Receptacle, U-Line Explosionproof Receptacle |
| Maximum Cable Outer Diameter | 0.639 Inch |
| Minimum Cable Outer Diameter | 0.538 Inch |
| Model | ECP |
| NEMA Rating | NEMA 7BCD, 9G |
| Noun | * |
| Number Of Poles | 3 |
| Number Of Wires | 2 |
| Product Description | 2W-3P PLUG |
| Product Keywords | WEBREADY |
| Product Name | Electrical plugs |
| ProductLine | APP |
| Special Features | Explosionproof, dust-ignitionproof; Suitable for use in such areas as refineries, petrochemical plants, and other areas subject to where ignitable gases are present; Unique blade-type, brass contacts exert constant pressure along entire contact surface and provide superior electrical contact; Insulators provide superior dielectric and mechanical strength and lowest arc tracking; Longer plug housing for better gripping and easier plug insertion and withdrawal; Plugs fits any standard non-explosionproof receptacle (NEMA 5-15R, 5-20R or 6-20R) as well as U-Line explosionproof receptacles; A twist of the plug produces audible click to indicate fast make and break of built-in switch contacts; Twisting plug locks it in place and cannot be accidentally pulled out. |
| Standard | Class I, Division 1 And 2, Groups B, C, D; Class II, Division 1 And 2, Group G and Coal Dust; Class III |
| Sub Brand | U-Line |
| Type | ECP Standard Plug |
| UNSPSC | 39121402 |
| UPC | 78138110587 |
| Vendor Name | APPLETON ELECTRIC COMPANY |
| Vendor Number | 781381 |
| Vendor Short Name | APP |
| Voltage Rating | 250 VAC;250 Volt AC |
