| Manufacturer Name | APPLETON ELECTRIC CO. |
| MfgPartNo | ENRC21201 |
| Additional Information | Overall Dimension 3.5 Inch Width x 6.19 Inch Depth x 6.81 Inch Height; Number of Conduit Opening 2; Material Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron (Mounting Box), Epoxy Powder Coated Copper-Free Aluminum (Cover); Application Light |
| Amperage Rating | 20 A |
| Application | For ECP Mating Plugs |
| Approval | UL 894/1010/1203 |
| Base Price | 0.0000 |
| Box Type | 1-Gang |
| Brand Name | U-Line[TM], Contender[TM] |
| Catalog Number | ENRC21201 |
| Commerce Sector | Construction Materials |
| Commodity Code | 51500 |
| Commodity Description | Pin & Sleeve Devices |
| CountryOfOrigin | MX |
| Current Rating | 20 Amp |
| DDCATEGORY | 576 |
| Directory | CIS |
| Enclosure | Class I Div 1 Group C D, Class I Div 2 Group B, Class II Div 1 and 2 Group F G, Class I Zone 1 Group IIB, Class I Zone 2 Group IIB + H2, Class III, NEMA 3/3R/3RX/7CD/9FG |
| Families | 576 |
| Family Description | Pin & Sleeve Devices |
| Hub Size | 3/4 Inch |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | SINGLE GANG RECEPT ASSY;1G RECEPT ASSY |
| Item Number | 81539 |
| Long Description | RECEPTACLE, FEED-THROUGH TYPE; 3/4 INCH HUB SIZE; 2 WIRE(S); UL 894/1010/1203 APPROVAL; 125 VOLT AC VOLTAGE RATING |
| MSDS Form Number | * |
| Material | Copperfree (4/10 Of 1 PCT Maximum) Aluminum Cover, Malleable Iron Mounting Box |
| Mating Plug | ECP |
| Mounting | Surface Mount |
| NEMA Rating | NEMA 3RX |
| Noun | * |
| Number Of Poles | 3 |
| Number Of Wires | 2 |
| Power Rating | 1 HP |
| Product Description | 1G RECEPT ASSY |
| Product Keywords | WEBREADY |
| Product Name | Electrical receptacles |
| ProductLine | APP |
| Special Features | Covers are UL Listed when used with Contender series back boxes;Dead front design: receptacle is not energized until plug is fully inserted and switch is engaged;ECP plug fits U-Line explosionproof receptacles;Explosionproof, dust-ignitionproof;Fiberglass reinforced thermoset polyester insulating blocks;For lighting systems, conveyors, heaters, motor-generator sets, air conditioners, compressors, pumps;Insulators provide superior dielectric and mechanical strength and lowest arc tracking;U-Line Contender receptacles only available for use in combination with 1- and 2-gang EDS boxes incorporating such devices as pilot lights, switches and push buttons |
| Standard | Class I, Division 2, Group B;Class I, Groups C, D;Class I, Zone 1, Group IIB;Class I, Zone 2, Group IIB + H2;Class II, Groups F, G;Class III;UL 1203, UL 1010, UL 894;UL Listed: E10784 |
| Type | 1-Gang Receptacle With Mounting Box;Feed-Through |
| UNSPSC | 39121406 |
| UPC | 78138181539 |
| Vendor Name | APPLETON ELECTRIC COMPANY |
| Vendor Number | 781381 |
| Vendor Short Name | APP |
| Voltage Rating | 125;125 Volt AC |
