| Manufacturer Name | APPLETON ELECTRIC CO. |
| MfgPartNo | EYDEF75AL |
| Additional Information | Constructional Feature Explosionproof/Dust Ignitionproof/Rain Tight; Length 4.31 Inch; Used On Threaded IMC/Rigid Metal Conduit; Application Hazardous Location; Applicable Standard NEC/CEC |
| Application | For Use With Threaded Rigid Metal Conduit and IMC |
| Approval | UL 886/1203, CSA C22.2 |
| Base Price | 0.0000 |
| Brand Name | Unilets[R] |
| Catalog Number | EYDEF75AL |
| Commerce Sector | Construction Materials |
| Commodity Code | 25220 |
| Commodity Description | Aluminum Sealing Bodies |
| Connection | Female Threaded |
| Connection Type | Tapered Threaded Female |
| CountryOfOrigin | MX |
| DDCATEGORY | 553 |
| Directory | CIS |
| Enclosure | Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III |
| Families | 553 |
| Family Description | Aluminum Sealing Bodies |
| Finish | Epoxy Powder Coat |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 3/4 EYD DRAIN SEAL-ALUM;3/4 DRAIN SEAL ALUM |
| Item Number | 80980 |
| Long Description | EXPLOSIONPROOF CONDUIT SEAL, DRAIN TYPE; EPOXY POWDER COATED COPPER-FREE ALMAG 35 ALUMINUM MATERIAL; TAPERED THREADED FEMALE CONNECTION TYPE; UL 886/1203, CSA C22.2 APPROVAL |
| MSDS Form Number | * |
| Material | Almag 35 Aluminum;Epoxy Powder Coated Copper-Free Almag 35 Aluminum |
| Model | EYDEF |
| Mounting Position | Vertical |
| Noun | * |
| Product Description | 3/4 DRAIN SEAL ALUM |
| Product Keywords | WEBREADY |
| Product Name | Electrical fittings |
| ProductLine | APP |
| Size | 3/4 |
| Special Features | A;Accurately tapped, tapered threads for tight, rigid joints and ground continuity;Explosionproof, dust-ignitionproof, raintight;For preventing passage of gases, vapors or flames from one portion of conduit system to another;Required in Class I, Division 1 and 2 locations at the boundary where conduit leaves classified location;Required in Class I, Division 1 and 2 locations where 2 IN or larger conduit enters enclosure, fitting housing terminals, splices or taps;Required in Class I, Division 1 and 2 locations where two or more enclosures are connected by 36 IN or less conduit, seal must be located within 18 IN of either enclosure;Required in Class I, Division 1 and 2 locations within 18 IN of enclosures containing apparatus that may cause arcs, sparks or high temperatures;Required where cables (which exceed rate of gas or vapor transmission permitted for seals) are used in Class I, Division 2 locations;Smooth, rounded integral bushing in each hub protects conductor insulation |
| Standard | And Class III;Class II, Groups E, F, G;UL 886 (1203), UL File Number E10444, CSA C22.2 No. 30, CSA 065181, UL Listed For Class I, Groups B, C, D |
| Trade Size | 3/4 Inch |
| Turning Radius | 1.38 Inch |
| Type | EY Series 40 PCT Expanded Fill Vertical Drain Sealing Fitting;Drain |
| UNSPSC | 39121311 |
| UPC | 78138180980 |
| Vendor Name | APPLETON ELECTRIC COMPANY |
| Vendor Number | 781381 |
| Vendor Short Name | APP |
