| Manufacturer Name | APPLETON ELECTRIC CO. |
| MfgPartNo | VMV5LCD5BU |
| Additional Information | Input Current Rating 0.2 Amp at 277 Volt AC, 0.16 Amp at 300 Volt DC; Input Power Rating 48 Watt at 277 Volt AC, 48 Watt at 300 Volt DC; Power Factor 0.97; Color Temperature 5000 Kelvin (Cool); Efficacy 107 Lumen per Watt; Color Rendering Index 70; Ambien |
| Amperage Rating | 1300 mA |
| Applicable Standard | NEC/CEC, ABS, IDA, DLC |
| Application | Pulp and Paper Mill, Processing/Manufacturing Plant, Waste Treatment, Warehouse |
| Approval | UL, CSA (Canada and US), CSA C22.2 |
| Area Classification | Marine/Wet Location |
| Average Life | 200,000 h |
| Base Price | 0.0000 |
| Brand Name | Contender[TM] |
| Bulb Spacing | 293.6 Mm |
| Catalog Number | VMV5LCD5BU |
| Color | Cool White |
| Commerce Sector | Construction Materials |
| Commodity Code | 72582 |
| Commodity Description | Led Wet Location Lighting |
| CountryOfOrigin | MX |
| DDCATEGORY | 3162 |
| Directory | CIS |
| Enclosure | Class I Div 1 and 2 Group D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/3R/4, IP66/67 |
| Families | 3162 |
| Family Description | Led Wet Location Lighting |
| Finish | Electrostatically Applied Baked Gray Epoxy Powder Coated |
| Fixture Type | LED Light |
| Housing Material | Copper-Free Cast Aluminum |
| Image Location | * Image |
| Industry | ELX |
| Input Voltage | 120/277 Volt AC 50/60 Hertz, 125/300 Volt DC |
| Intensity | 5150 Lumen |
| InvoiceDescription | CNTLED, 5000LM, CW, DPC, 120-277V;LED LIGHT FIXTURE |
| Item | Luminaire |
| Item Number | 19525 |
| LUMENS | 5 K |
| Lamp Type | LED |
| Life In Hour | 60000 |
| Long Description | LED ENCLOSED AND GASKETED LIGHT FIXTURE, 11.6 INCH WIDTH X 6 INCH HEIGHT SIZE; ELECTROSTATICALLY APPLIED BAKED GRAY EPOXY POWDER COATED FINISH; UL, CSA (CANADA AND US), CSA C22.2 APPROVAL; NEC/CEC, ABS, IDA, DLC APPLICABLE STANDARD |
| MSDS Form Number | * |
| Model | VMV |
| Mounting | APM2, APM3, HPM2, CM2, CM3, TWM2, TWM3,QM25, JM5, PM5 |
| Noun | * |
| Power Sources | 120-277, 50/60, 125-300 Vac,Hz,Vdc |
| Product Description | LED LIGHT FIXTURE |
| Product Keywords | WEBREADY |
| Product Name | Light emitting diode LED optic lighting |
| ProductLine | APP |
| Reflector Type | Fiberglass Reinforced White Polyester |
| Refractor Type | NEMA Type 5 Diffused Polycarbonate Globe |
| Size | 5.76-11.56 in;11.6 Inch Width x 6 Inch Height |
| Special Features | Standard 6 kV surge protection,Heavy duty, high temperature silicone rubber gaskets. |
| Standard | UL Approved, CSA Approved |
| UNSPSC | 39112102 |
| UPC | 78138119525 |
| Vendor Name | APPLETON ELECTRIC COMPANY |
| Vendor Number | 781381 |
| Vendor Short Name | APP |
| Voltage Rating | 120-277 Vac |
| Wattage | 48 W |
