| Manufacturer Name | BURNDY (FCI BURNDY) |
| MfgPartNo | 50X200HEBBOX |
| Additional Information | RoHS Compatible; Installation Torque 480 Lb-Inch |
| Application | For Use On Outdoor Connector Applications |
| Base Price | 0.0000 |
| Brand Name | DURIUM[TM] |
| Catalog Number | 50X200HEBBOX |
| Certification CSA Approved | No |
| Certification CULus | No |
| Certification ETL | No |
| Certification UL Recognized | No |
| Certified Listed | Buy American Act Compliant (All status valid till December 2024) |
| Commerce Sector | Construction Materials |
| Commodity Code | 65310 |
| Commodity Description | Screws,Nuts,Bolts,Washers |
| CountryOfOrigin | US |
| DDCATEGORY | 600 |
| Description Long | Silicon Bronze Bolt, 2 in L, Thread Series Class-2A. |
| Description Short | Silicon Bronze Bolt, 2 in L, Thread Series Class-2A |
| Description Slang | DURIUM Silicon Bronze |
| Dimension B Length Fraction | 2 in |
| Dimension B Length Inch | 2 in |
| Dimension Bolt Size Fraction | 1/2 |
| Dimension Bolt Size Inch | 0.5 in |
| Dimension Length Overall Inch | 2 in |
| Dimension Thread Size | 1/2-13 |
| Dimension Threads Per Inch | 13 |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| FEATURES Bullets | DURIUM silicon bronze hardware combines high strength and corrosion resistance;Silicon bronze per ASTM B99 |
| FV BuyAmericanCompliant | Contact Manufacturer |
| FV Certified Listed | Buy American Act Compliant (All status valid till December 2024) |
| FV Dimension B Length Inch | 2 in |
| FV Dimension Bolt Size Fraction | 1/2 |
| FV Dimension Thread Size | 1/2-13 |
| FV Dimension Threads Per Inch | 13 |
| FV Product Family | Hardware/Inhibitors/Sealants>Silicon Bronze>Nuts, Bolts, Flat Washers, U-Bolts, Kits |
| FV Trade Name | DURIUM |
| Families | 600 |
| Family Description | Screws,Nuts,Bolts,Washers |
| Head Height | 0.364 Inch |
| Head Width Across Flat | 0.75 Inch |
| Image Location | * Image |
| Industry | ELX |
| Installation Torque Recommended In Lb | 480 LBS/in |
| InvoiceDescription | 1/2 X 2 HEX BOLT-BOXED;DURIUM BOLT |
| Item Number | 01178 |
| Length | 2 in |
| Long Description | BOLT, FULLY THREADED TYPE; SILICON BRONZE MATERIAL; 0.364 INCH HEAD HEIGHT; 0.75 INCH HEAD WIDTH ACROSS FLAT; 2 INCH THREAD LENGTH; 3/4 INCH NOMINAL DIAMETER; UNC-2A THREAD SERIES; 13 TPI; ASTM B99 MATERIAL SPECIFICATION; DURIUM[TM] BRAND |
| MSDS Form Number | * |
| Material | Silicon Bronze |
| Material Specification | ASTM B99 |
| Minimum Pack Quantity | 1 |
| Nominal Diameter | 3/4 Inch |
| Noun | * |
| Pallet Quantity | 9600 |
| Product Description | 1/2 X 2 HEX BOLT-BOXED |
| Product Keywords | WEBREADY |
| Product Name | "50X200HEBBOX, 1/2"" x 2"" Hex Bolt, Silicon Bronze" |
| Product Type | BOLT |
| ProductLine | BUR |
| Size | 2 in x 0.5 in x 0.364 in |
| Special Features | Durium Bolts combine high strength with corrosion resistance |
| Standard | Buy American Act Compliant (All status valid till December 2024) | |
| TPI | 13 |
| Thread Length | 2 Inch |
| Thread Series | UNC-2A |
| Type | Bolt;Fully Threaded |
| UNSPSC | 31161620 |
| UPC | 78181001178 |
| Vendor Name | BURNDY PRODUCTS |
| Vendor Number | 781810 |
| Vendor Short Name | BUR |
