Manufacturer Name | BURNDY (FCI BURNDY) |
MfgPartNo | BIBD2502 |
Additional Information | ROHS COMPATIBLE; HEX KEY SIZE 5/16 INCH; SIZE 2.03 INCH L X 2.64 INCH W X 2.13 INCH H; TEMPERATURE RATING 90 DEG C; FEATURES OXIDE INHIBITOR, RANGE TAKING CAPABILITY; APPLICATION INDOOR; TYPE OF INSULATION CLEAR PLASTISOL |
Application | For Indoor Use Only, Copper Or Stranded Aluminum |
Approval | UL, CSA |
Base Price | 0.0000 |
Body Material | Aluminum |
Brand Name | Burndy;UNITAP[TM] |
Cable Entry | 2-Sided Entry |
Catalog Number | BIBD2502 |
Certification CSA Approved | Yes |
Certification CULus | No | |
Commerce Sector | Construction Materials |
Commodity Code | 64130 |
Commodity Description | Splicing & Terminating Kits |
Conductor Material | Aluminum/Copper |
Conductor Size | 10 AWG-250 KCMIL |
CountryOfOrigin | US |
DDCATEGORY | 597 |
Description Long | Aluminum Multiple Tap Connector, Clear Insulated, 2 Port, 2 Sided Entry, 10 AWG-250 kcmil, Al/Cu Rated. |
Description Short | Aluminum Multiple Tap Connector, Clear Insulated, 2 Port, 2 Sided Entry, 10 AWG-250 kcmil, Al/Cu Rated |
Description Slang | Clear Insulation |
Dimension Height Fraction | 2.125 in |
Dimension Height Inch | 2.13 in |
Dimension L Length Overall Mm | 52 mm |
Dimension Length Overall Inch | 2.03 in |
Dimension Width Fraction | 2-16/25 in |
Dimension Width Inch | 2.64 in |
Dimension Width Mm | 67 mm |
Directory | CIS |
EU RoHS Indicator | Yes |
Families | 597 |
Family Description | Large Terminals & Connectors |
Hex Key | 5/16 |
Image Location | * Image |
Industry | ELX |
Insulation Type | Plastisol |
InvoiceDescription | 250-10 TWO SIDED UNITAP,2.03 IN L;MULTIPLE WIRE TERM |
Item Number | 22405 |
Long Description | MULTIPLE TAP CONNECTOR, 10 AWG STRANDED MIN. CONDUCTOR SIZE; 250 KCMIL STRANDED MAX. CONDUCTOR SIZE; ALUMINUM/COPPER CONDUCTOR MATERIAL; UL, CSA APPROVAL; 600 VOLT VOLTAGE RATING; ALUMINUM BODY MATERIAL; 2 PORT(S); 2-SIDED ENTRY CABLE ENTRY |
MSDS Form Number | * |
Material | Aluminum |
Material Hardware | Aluminum |
Maximum Conductor Size | 250 KCMIL Stranded |
Minimum Conductor Size | 10 AWG Stranded |
Minimum Pack Quantity | 1 |
Model | BIBD |
Noun | * |
Number Of Ports | 2 |
Physical Attribute Number Of Screws | 2 |
Physical Attribute Screw Type | Allen |
Plated | N |
Plating Type | Unplated |
Product Description | 250-10 TWO SIDED UNITAP,2.03 IN L |
Product Keywords | WEBREADY |
Product Name | Double Sided Two Conductor Clear Insulated Mult-Tap Connector |
Product Type | RUN/TAP |
ProductLine | BUR |
Rating Minimum Voltage | 600 |
Special Features | Clear Plastisol covered AL6061-T6 aluminum body, Clear Plastisol |
Standard | UL 486A-486B |
Standards Industry Standards Met | UL 486A-486B |
Standards RoHS Compliance Status | CM |
Sub Brand | UNITAP |
Temperature Rating | 194 |
Trade Name | UNITAP |
Type | BIBD, Multi-Port |
UL Listed | Yes |
UNSPSC | 39121427 |
UPC | 78181022405 |
Vendor Name | BURNDY PRODUCTS |
Vendor Number | 781810 |
Vendor Short Name | BUR |
Voltage Rating | 600 Volt |
