| Manufacturer Name | BURNDY (FCI BURNDY) |
| MfgPartNo | BIBS2508 |
| Additional Information | RoHS Compatible; Temperature Rating 90 Deg C; Size 7.66 Inch L x 2.07 Inch W x 2.13 Inch H; Hex Key Size 5/16 Inch; Number Of Screw 8 |
| Application | For Indoor Use Only, Copper Or Stranded Aluminum |
| Approval | UL 486B, CSA |
| Base Price | 0.0000 |
| Body Material | Clear Plastisol Covered AL6061-T6 Aluminum |
| Brand Name | UNITAP[TM] |
| Cable Entry | 1 Side Entry |
| Catalog Number | BIBS2508 |
| Certification CSA Approved | Yes |
| Certification CULus | No |
| Certification ETL | No |
| Certification UL Listed Direct Burial | No |
| Certification UL Recognized | No |
| Commerce Sector | Construction Materials |
| Commodity Code | 64130 |
| Commodity Description | Splicing & Terminating Kits |
| Conductor Material | Aluminum/Copper |
| Conductor Size | 10 AWG-250 KCMIL |
| CountryOfOrigin | US |
| DDCATEGORY | 597 |
| Description Long | Aluminum Multiple Tap Connector, Clear Insulated, 8 Port, 1 Sided Entry, 10 AWG-250 kcmil, Al/Cu Rated. |
| Description Short | Aluminum Multiple Tap Connector, Clear Insulated, 8 Port, 1 Sided Entry, 10 AWG-250 kcmil, Al/Cu Rated |
| Description Slang | Clear Insulation |
| Dimension Height Inch | 2.13 in |
| Dimension L Length Overall Mm | 195 mm |
| Dimension Length Overall Inch | 7.66 in |
| Dimension Width Inch | 2.07 in |
| Dimension Width Mm | 53 mm |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| FEATURES Bullets | Clear Plastisol covered AL6061-T6 aluminum body saves times and lowers installation costs and eliminates taping;Clear plastisol allows visual confirmation that conductor is properly inserted;Oxide inhibitor pre-installed inhibits moisture and contaminants from entering the contact area;Range-taking capability reduces number of connectors necessary to carry in inventory |
| FV BuyAmericanCompliant | No |
| FV Conductor AL Str Size Range | 10 AWG - 250 kcmil |
| FV Conductor Copper Str Size Range | 10 AWG - 250 kcmil |
| FV Product Family | MECHANICAL |
| FV Standards Industry Standards Met | UL 486A-486B |
| FV Trade Name | UNITAP |
| Families | 597 |
| Family Description | Large Terminals & Connectors |
| Hex Key | 5/16 |
| Image Location | * Image |
| Industry | ELX |
| Insulation Type | Plastisol |
| InvoiceDescription | 250-10, ONE SIDE UNI-TAP;MULTIPLE WIRE TERM |
| Item Number | 13178 |
| Long Description | MECHANICAL MULTIPLE TAP CONNECTOR, 8 AWG (ALUMINUM), 10 AWG STRANDED (COPPER) MIN. CONDUCTOR SIZE; 250 KCMIL (ALUMINUM), 250 KCMIL STRANDED (COPPER) MAX. CONDUCTOR SIZE; ALUMINUM/COPPER CONDUCTOR MATERIAL; UL 486B, CSA APPROVAL; 600 V VOLTAGE RATING |
| MSDS Form Number | * |
| Material | Aluminum |
| Maximum Conductor Size | 250 KCMIL (Aluminum), 250 KCMIL Stranded (Copper) |
| Minimum Conductor Size | 8 AWG (Aluminum), 10 AWG Stranded (Copper) |
| Minimum Pack Quantity | 1 |
| Model | BIBS |
| Noun | * |
| Number Of Ports | 8 |
| Pallet Quantity | 1080 |
| Physical Attribute Number Of Screws | 8 |
| Physical Attribute Screw Type | Allen |
| Plated | N |
| Plating Type | Unplated |
| Product Description | 250-10, ONE SIDE UNI-TAP |
| Product Keywords | WEBREADY |
| Product Name | BIBS2508, Single Sided Eight Conductor Clear Insulated Multi-Tap Connector |
| Product Type | RUN/TAP |
| ProductLine | BUR |
| Standard | UL 486A-486B |
| Standards Industry Standards Met | UL 486A-486B |
| Standards RoHS Compliance Status | CM | |
| UNSPSC | 39121427 |
| UPC | 78181013178 |
| Vendor Name | BURNDY PRODUCTS |
| Vendor Number | 781810 |
| Vendor Short Name | BUR |
| Voltage Rating | 600 V |
