| Manufacturer Name | BURNDY (FCI BURNDY) |
| MfgPartNo | KPA4C |
| Additional Information | RoHS Compliant; Overall Height 0.94 Inch; Installation Torque 35 Inch-Pound; Number of Screw 1 |
| Application | For Joining A Wide Range Of Cable To Equipment Pads Or Terminal Blocks, Especially Good In Light Industrial Applications |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand Name | SCRULUG[TM] |
| Catalog Number | KPA4C |
| Certification CSA Approved | Yes |
| Certification CULus | No |
| Certification ETL | No |
| Certification UL Listed Direct Burial | No |
| Certification UL Recognized | No |
| Certified Listed | TAA Compliant (All status valid till December 2024) |
| Commerce Sector | Construction Materials |
| Commodity Code | 64120 |
| Commodity Description | Large Terminals & Connectors |
| Conductor Material | Copper |
| CountryOfOrigin | US |
| DDCATEGORY | 597 |
| Description Long | "Copper Terminal, 1 Hole, 14 AWG (Sol)-4 AWG (Str), 1/4"" Stud, 1 Screw, Tin Plated." |
| Description Short | "Copper Terminal, 1 Hole, 14 AWG (Sol)-4 AWG (Str), 1/4"" Stud, 1 Screw, Tin Plated" |
| Description Slang | SCRULUG KPA |
| Dimension Bolt Size Fraction | 1/4 |
| Dimension D Inch | 0.59 in |
| Dimension Height Fraction | 47/50 in |
| Dimension Height Inch | 0.94 in |
| Dimension Hole Size Inch | 0.27 in |
| Dimension Hole Size Mm | 7 mm |
| Dimension L Length Overall Mm | 31 mm |
| Dimension Length Overall Inch | 1.22 in |
| Dimension N Inch | 0.30 in |
| Dimension Pad Width Inch | 0.50 in |
| Dimension Stud Size Inch | 1/4 |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| FEATURES Bullets | High copper alloy terminal (tin-plated) for joining a wide range of cable to equipment pads or terminal blocks;Tongue and body are 1-piece design, pressure bar equalizes pressure over the conductor and prevents the screw from cutting into the cable |
| FV BuyAmericanCompliant | No |
| FV Certified Listed | TAA Compliant (All status valid till December 2024) |
| FV Product Family | MECHANICAL |
| FV Trade Name | SCRULUG |
| Families | 597 |
| Family Description | Large Terminals & Connectors |
| Image Location | * Image |
| Industry | ELX |
| Installation Torque Recommended In Lb | 35 LBS/in |
| InvoiceDescription | SCRULUG,#4 Str-#14 Sol;4STR COP 1H TERM LUG |
| Item Number | 35135 |
| Long Description | TERMINAL LUG, TIN PLATED HIGH COPPER ALLOY MATERIAL; 1.22 INCH OVERALL LENGTH; 14 AWG SOLID/STRANDED MIN. CONDUCTOR SIZE; 4 AWG SOLID/STRANDED MAX. CONDUCTOR SIZE; COPPER CONDUCTOR MATERIAL; UL, CSA APPROVAL; 1 CONDUCTOR(S); 1/4 INCH STUD SIZE |
| MSDS Form Number | * |
| Material | Copper;Tin Plated High Copper Alloy |
| Maximum Conductor Size | 4 AWG Solid/Stranded |
| Minimum Conductor Size | 14 AWG Solid/Stranded |
| Minimum Pack Quantity | 1 |
| Model | KPA |
| Noun | * |
| Number Of Conductors | 1 |
| Number Of Pad Holes | 1 |
| Overall Length | 1.22 Inch |
| Pad Size | 0.59 Inch Length x 0.5 Inch Width x 0.06 Inch Thickness |
| Pad Type | Equipment |
| Pallet Quantity | 59400 |
| Physical Attribute Number Of Screws | 1 |
| Physical Attribute Screw Type | Slot |
| Plated | Y | |
| Product Description | SCRULUG,#4 Str-#14 Sol |
| Product Keywords | WEBREADY |
| Product Name | Mechanical connectors |
| ProductLine | BUR |
| Screw Type | Slotted Head |
| Special Features | Features: High Copper Alloy Tin-Plated Terminal For Joining A Wide Range Of Cable To Equipment Pads Or Terminal Blocks, Especially Good In Light Industrial Applications, The Tongue And Body Are A One-Piece Design, The Pressure Bar Equalizes Pressure Over The Conductor And Prevents The Screw From Cutting Into The Cable, Stud/bolt Size: 5/16 IN, Stud/bolt Hole Size: 1/4 IN, Installation Torque: 35 IN-LB, Set Screw Type: Slot Robertson, Dimension N: 0.3 IN, Length: 1.2 IN, Width: 0.5 IN, Height: 0.94 IN, Tongue Width : 0.5 IN, Dimension D: 0.59 IN, Dimension K: 0.27 IN, Dimension T: 06 IN |
| Standard | UL 486A-486B |
| Stud Size | 1/4 Inch |
| Type | Bolted Lugs & Terminals |
| UNSPSC | 39121408 |
| UPC | 78181035135 |
| Vendor Name | BURNDY PRODUCTS |
| Vendor Number | 781810 |
| Vendor Short Name | BUR |
