| Manufacturer Name | BURNDY (FCI BURNDY) |
| MfgPartNo | KSU17 |
| Application | For All Combinations Of Copper, Aluminum, ACSR, AAAC, 5005, And Steel |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand Name | UNIVERSAL SERVIT[R] |
| Catalog Number | KSU17 |
| Certification CSA Approved | No |
| Certified Listed | TAA Compliant (All status valid till December 2024) |
| Commerce Sector | Construction Materials |
| Commodity Code | 64120 |
| Commodity Description | Large Terminals & Connectors |
| Conductor Material | Copper/Aluminum/ACSR/AAAC/5005 |
| CountryOfOrigin | US |
| DDCATEGORY | 597 |
| Description Long | Tin-plated, high strength copper alloy SERVIT with spacer. Spacer separates dissimilar conductors and provides long contact length. |
| Description Short | Tin-plated, high strength copper alloy SERVIT with spacer. Spacer separates dissimilar conductors and provides long contact length |
| Dimension Cross Flats Inch | .62 in |
| Dimension L Length Overall Mm | 23 mm |
| Dimension Length Overall Inch | 1.14 |
| Dimension Width Inch | 0.42 in |
| Dimension Width Mm | 11 mm |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| FEATURES Bullets | Spacer separates dissimilar conductors and provides long contact length preventing high pressure point contacts between run and tap conductors;Tin-plated, high strength copper alloy with spacer |
| FV BuyAmericanCompliant | No |
| FV Certified Listed | TAA Compliant (All status valid till December 2024) |
| FV Product Family | Power Connectors>Split Bolts>KSU |
| Families | 597 |
| Family Description | Large Terminals & Connectors |
| Image Location | * Image |
| Industry | ELX |
| Installation | Split Bolt |
| Installation Torque Recommended In Lb | 165 LBS/in |
| InvoiceDescription | SERVIT UNIV 6R-6T AL/CU;8AWG SPLIT BOLT CONN |
| Item Number | 03500 |
| Long Description | MECHANICAL CONNECTOR, TIN PLATED COPPER MATERIAL; 12 AWG SOLID (COPPER/ALUMINUM), 8 AWG (ACSR/AAAC 5005) MIN. RUN CONDUCTOR SIZE; 6 AWG SOLID (COPPER/ALUMINUM), 8 AWG (ACSR/AAAC 5005) MAX. RUN CONDUCTOR SIZE |
| MSDS Form Number | * |
| Material | Copper;Tin Plated Copper |
| Maximum Run Conductor Size | 6 AWG Solid (Copper/Aluminum), 8 AWG (ACSR/AAAC 5005) |
| Maximum Tap Conductor Size | 6 AWG Solid (Copper/Aluminum), 8 AWG (ACSR/AAAC 5005) |
| Minimum Pack Quantity | 1 |
| Minimum Run Conductor Size | 12 AWG Solid (Copper/Aluminum), 8 AWG (ACSR/AAAC 5005) |
| Minimum Tap Conductor Size | 12 AWG Solid (Copper/Aluminum), 8 AWG (ACSR/AAAC 5005) |
| Model | KSU |
| Noun | * |
| Pallet Quantity | 29700 |
| Plated | Y |
| Plating Type | Tin Plated |
| Product Description | SERVIT UNIV 6R-6T AL/CU |
| Product Keywords | WEBREADY |
| Product Name | KSU17, Split Bolt Connector with Spacer, Tin Plated |
| Product Type | Mechanical |
| ProductLine | BUR |
| Special Features | Features: Tin-Plated, High Strength Copper Alloy SERVIT With Spacer, Spacer Separates Dissimilar Conductors And Provides Long Contact Length That Prevents High Pressure Point Contacts Between Run And Tap Conductors, Use Of PENETROX Joint Compound Recommended With Aluminum And ACSR, Conductor Type: Run: ACSR, 5005, AAAC, Commercial Stranded Aluminum, Commercial Stranded And Solid Copper, Tap: ACSR, 5005, AAAC, Commercial Stranded Aluminum, Commercial Stranded And Solid Copper, Steel (Nominal Diameter), Installation Torque: 165 IN-LB, Length: 0.92 IN, Cross Flats: 0.62 IN, Width: 0.42 IN |
| Standard | TAA Compliant (All status valid till December 2024) |
| Standards RoHS Compliance Status | CM |
| Trade Name | SERVIT |
| Type | KSU, Universal |
| UL Listed | Yes |
| UNSPSC | 39121408 |
| UPC | 78181003500 |
| Vendor Name | BURNDY PRODUCTS |
| Vendor Number | 781810 |
| Vendor Short Name | BUR |
