| Manufacturer Name | BURNDY (FCI BURNDY) |
| MfgPartNo | KSU26 |
| Additional Information | RoHS Compliant; Torque Rating 385 Inch-Pound; Cross Flat 1.04 Inch |
| Application | For All Combinations Of Copper, Aluminum, ACSR, AAAC, 5005, And Steel |
| Approval | UL 486A |
| Base Price | 0.0000 |
| Brand Name | SERVIT [R] |
| Catalog Number | KSU26 |
| Certification CSA Approved | No |
| Certified Listed | Buy American Act Compliant (All status valid till December 2024) |
| Commerce Sector | Construction Materials |
| Commodity Code | 64120 |
| Commodity Description | Large Terminals & Connectors |
| Conductor Material | Copper/Aluminum/ACSR/AAAC/5005/Steel |
| CountryOfOrigin | US |
| DDCATEGORY | 597 |
| Description Long | Tin-plated, high strength copper alloy SERVIT with spacer. Spacer seperates dissimilar conductors and provides long contact length that prevents high pressure point contacts between run and tap conductors, 1.90 IN L. |
| Description Short | Tin plated copper alloy SERVIT with spacer to separate dissimilar conductors |
| Dimension Cross Flats Inch | 1.04 in |
| Dimension L Length Overall Mm | 49 mm |
| Dimension Length Overall Inch | 1.95 |
| Dimension Width Inch | 0.79 in |
| Dimension Width Mm | 20 mm |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| FEATURES Bullets | Spacer separates dissimilar conductors and provides long contact length preventing high pressure point contacts between run and tap conductors;Tin-plated, high strength copper alloy with spacer |
| FV BuyAmericanCompliant | Contact Manufacturer |
| FV Certified Listed | Buy American Act Compliant (All status valid till December 2024) |
| FV Product Family | Power Connectors>Split Bolts>KSU |
| Families | 597 |
| Family Description | Large Terminals & Connectors |
| Image Location | * Image |
| Industry | ELX |
| Installation | Spacer |
| Installation Torque Recommended In Lb | 385 |
| InvoiceDescription | SERVIT UNIV 1/0-2/0;2/0AWG SPLIT BOLT CONN |
| Item Number | 03660 |
| Long Description | MECHANICAL CONNECTOR, UNIVERSAL TYPE; ELECTRO TIN PLATED HIGH STRENGTH COPPER ALLOY MATERIAL; 2 AWG STRANDED (COPPER/ALUMINUM), 1 AWG (ACSR/AAAC/5005) MIN. RUN CONDUCTOR SIZE |
| MSDS Form Number | * |
| Material | Copper;Electro Tin Plated High Strength Copper Alloy |
| Maximum Run Conductor Size | 2/0 AWG Stranded (Copper/Aluminum), 1/0 AWG (ACSR/AAAC/5005), 7/16 Inch (Steel) |
| Maximum Tap Conductor Size | 2/0 AWG Stranded (Copper/Aluminum), 1/0 AWG (ACSR/AAAC/5005), 7/16 Inch (Steel) |
| Minimum Pack Quantity | 1 |
| Minimum Run Conductor Size | 2 AWG Stranded (Copper/Aluminum), 1 AWG (ACSR/AAAC/5005) |
| Minimum Tap Conductor Size | 8 AWG Stranded (Copper/Aluminum), 6 AWG (ACSR/AAAC/5005) |
| Model | KSU |
| Noun | * |
| Pallet Quantity | 5800 |
| Plated | Y |
| Plating Type | Tin Plated |
| Product Description | SERVIT UNIV 1/0-2/0 |
| Product Keywords | WEBREADY |
| Product Name | KSU26, Split Bolt Connector with Spacer. Tin Plated |
| Product Type | Mechanical |
| ProductLine | BUR |
| Special Features | Features: Tin-Plated, High Strength Copper Alloy SERVIT With Spacer, Spacer Separates Dissimilar Conductors And Provides Long Contact Length That Prevents High Pressure Point Contacts Between Run And Tap Conductors, Use Of PENETROX Joint Compound Recommended With Aluminum And ACSR, Conductor Type: Run: ACSR, 5005, AAAC, Commercial Stranded Aluminum, Commercial Stranded And Solid Copper, Tap: ACSR, 5005, AAAC, Commercial Stranded Aluminum, Commercial Stranded And Solid Copper, Steel (Nominal Diameter), Installation Torque: 385 IN-LB, Width: 0.79 IN, Cross Flats: 14 IN, Length: 1.93 IN |
| Standard | Buy American Act Compliant (All status valid till December 2024) |
| Standards RoHS Compliance Status | CM |
| Trade Name | SERVIT |
| Type | KSU, Universal;Universal |
| UL Listed | Yes |
| UNSPSC | 39121408 |
| UPC | 78181003660 |
| Vendor Name | BURNDY PRODUCTS |
| Vendor Number | 781810 |
| Vendor Short Name | BUR |
