| Manufacturer Name | BUSSMANN |
| MfgPartNo | 160LMT |
| Additional Information | RoHS Compliant; Mounting Type Stud; Power Loss 17 Watt; Application DC Common Bus, DC Drive, Power Converter/Rectifier, Reduced Voltage Starter |
| Amperage Rating | 160 A |
| Applicable Standard | BS88-4, IEC 60269-4 |
| Application | Ind Facilities & Factories - Facility: Safety and Security SystemsElec Assemblies, Panels & EOEM - Panel BuildersElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - OtherElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsInd Facilities & Factories - Facility: Power Distribution and ControlElec Assemblies, Panels & EOEM - Control Panels for MachinesElec Assemblies, Panels & EOEM - Elec Assemblies/Panels/EOEMs - Aftermarket |
| Approval | UL, CE, CCC |
| Base Price | 0.0000 |
| Brand Name | Eaton |
| Catalog Number | 160LMT |
| Characteristics | High Speed |
| Class | Class aR |
| Commerce Sector | Construction Materials |
| Commodity Code | 61200 |
| Commodity Description | Small Dimension Fuses |
| Connection | Blade end x blade end |
| CountryOfOrigin | IN |
| Current Rating | 160 Amp |
| DDCATEGORY | 281 |
| Dimensions | 3.3071 IN X 1.5354 IN X 1.6142 IN |
| Directory | CIS |
| Families | 281 |
| Family Description | Small Dimension Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 200 kA RMS Sym, 40 kA at 150 Vdc (IEC)200 kA RMS Sym, 50 kA at 150 Vdc (UL) |
| Interrupting Rating | 200 Kiloamp (Symmetrical) |
| InvoiceDescription | 160AMP 240V AC BS88 FUSE;160A 240V AC BS88 FUSE;LOW VOLTAGE FUSE |
| Item Number | 83160 |
| Long Description | LOW VOLTAGE FUSE, TYPE LMT TYPE; 38.1 MILLIMETER DIAMETER X 84 MILLIMETER LENGTH SIZE; UL, CE, CCC APPROVAL; BS88-4, IEC 60269-4 APPLICABLE STANDARD; 240 VOLT AC/150 VOLT DC (IEC), 250 VOLT AC/150 VOLT DC (UL) VOLTAGE RATING |
| MSDS Form Number | * |
| Model | LMT |
| Mounting | Stud |
| Noun | * |
| Product Description | 160AMP 240V AC BS88 FUSE |
| Product Keywords | WEBREADY |
| Product Name | Semiconductor fuse |
| ProductLine | BUSS |
| Size | 84.00 mm Length X 38.10 mm Width X 41.00 mm Height;38.1 Millimeter Diameter x 84 Millimeter Length |
| Special Features | Low Arc Voltage, Excellent Cycling Capacity, Excellent DC Performance, Power Loss 17 W, Interrupt Rating 200 kA (RMS Symmetrical) |
| Standard | IEC Rated ,UL Recognized ,Designed and tested to BS88 part 4 ,UL recognized ,CCC ,IEC 60269-4,RoHS Compliant,CE Marked;IEC Rated,UL Recognized,Designed and tested to BS88 part 4,UL recognized,CCC,IEC 60269-4,RoHS Compliant,CE Marked |
| Sub Brand | Bussmann Series |
| Terminal Type | Bolted Blade |
| Type | High speed British standard fuse;Type LMT |
| Type Of Indicators | Non-Indicating |
| UNSPSC | 39121628 |
| UPC | 05171283160 |
| Vendor Name | EATON BUSSMANN |
| Vendor Number | 051712 |
| Vendor Short Name | BUSS |
| Voltage Rating | 240//150 VAC//VDC;240 Volt AC/150 Volt DC (IEC), 250 Volt AC/150 Volt DC (UL) |
