BUSS 170M5508

FUSE 400A 690V 2GN/50 AR UC

Page Loading...
BUSSMANN
FUSE 400A 690V 2GN/50 AR UC

Mouse over image to zoom, click to enlarge

Description:
FUSE 400A 690V 2GN/50 AR UC

UPC:  05171226148

Part Number: 170M5508

UNSPSC: 39121628

Status:  UNKNOWN

Retail Price:  $1,325.32 / EA
Your Price:  $608.30 / EA


Quantity  EA

Specifications

Manufacturer Name BUSSMANN
MfgPartNo 170M5508
Amperage Rating 400 A
Application Ind Facilities & Factories - Facility: Safety and Security Systems
Base Price 0.0000
Class Class aR
Connection Flush-end contact
CountryOfOrigin MUL
DDCATEGORY 580
Dimensions 3.0315 IN X 2.4016 IN X 2.0079 IN
Families 580
Family Description Renewable & Non-Renewable Fuses
Height 2.087 in
Interrupt Rating 200 kA
InvoiceDescription FUSE 400A 690V 2GN/50 AR UC;400A FUSE
Length 5.433 in
Mounting Flush
Product Description FUSE 400A 690V 2GN/50 AR UC
Product Keywords WEBREADY
Product Name Semiconductor fuse
ProductLine BUSS
Size 51 mm Length X 61 mm Width X 77 mm Height
Special Features Low Arc Voltage, Excellent DC Performance, Superior Cycling Capability, Designated Size 2
Standard ćadavky RoHS,Opatřeno značIEC ,UL Recognized ,UL Recognized ,Parametry dle IEC,CE Marked,RoHS Compliant,CE-Kennzeichnung,RoHS-konform,Uzyskano oznaczenie CE,Zgodny z IEC Rated ,UL Recognized ,IEC-Einstufung ,UL Recognized ,Zgodnośkou CE;uje požwymogami RoHS,Splňz
Type High speed square body fuse
UNSPSC 39121628
UPC 05171226148
Voltage Rating 1300 V (UL), 1100 V (IEC)
WEIGHT 1.6456 lb
Width 0.315 in

Resources

CatalogNumber 170M5508
Full Image

Package Information

SellPkgQty 1
