BUSS 170M6810D

FUSE 630A 690V aR DIN 3 HSDNH

Page Loading...
BUSSMANN
FUSE 630A 690V aR DIN 3 HSDNH

Mouse over image to zoom, click to enlarge

Description:
FUSE 630A 690V aR DIN 3 HSDNH

UPC:  05171233523

Part Number: 170M6810D

UNSPSC: 39121628

Status:  UNKNOWN

Retail Price:  $1,680.37 / EA
Your Price:  $771.26 / EA


Quantity  EA

Specifications

Manufacturer Name BUSSMANN
MfgPartNo 170M6810D
Amperage Rating 630 A
Application Ind Facilities & Factories - Facility: Safety and Security SystemsElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - OtherInd Facilities & Factories - Facility: Critical Power
Base Price 0.0000
Class Class aR
Connection Din 43-620 blade end x Din 43-620 blade end
CountryOfOrigin MUL
DDCATEGORY 580
Dimensions 5.9055 IN X 2.7953 IN X 3.4252 IN
Families 580
Family Description Renewable & Non-Renewable Fuses
Height 2.087 in
Interrupt Rating 200 kA
InvoiceDescription FUSE 630A 690V aR DIN 3 HSDNH;630A FUSE
Length 5.433 in
Product Description FUSE 630A 690V aR DIN 3 HSDNH
Product Keywords WEBREADY
Product Name Semiconductor fuse
ProductLine BUSS
Size 150 mm Length X 76 mm Width X 88 mm Height
Special Features Low Arc Voltage, Excellent DC Performance, Superior Cycling Capability, Designated Size 3
Standard ćadavky RoHS,OpatřCEI ,Reconnu UL,CE Marked,RoHS Compliant,CE-Kennzeichnung,RoHS-konform,Conforme a RoHS,Con marchio CE,RoHS-compliant,CE-markering,Uzyskano oznaczenie CE,Zgodny z eno značIEC ,UL Recognized ,Parametry dle IEC ,Clasificaciókou CE,Compatible con RoHS,Con marca CE,Conformitén IEC ,UL Recognized ,HomologuéRoHS,Marquage CE;uje požUL Recognized ,IEC Rated ,IEC-Einstufung ,UL Recognized ,Classificazione IEC ,UL Recognized ,UL Recognized ,IEC nominaal ,UL Recognized ,Zgodnośwymogami RoHS,Splňz
Type High speed square body fuse
UNSPSC 39121628
UPC 05171233523
Voltage Rating 690 V (IEC), 700 V (UL)
WEIGHT 1.6456 lb
Width 0.315 in

Resources

CatalogNumber 170M6810D
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
