BUSS FNQ-R-12

CLASS CC TIME DELAY REJECTION FUSE

Page Loading...
BUSSMANN
CLASS CC TIME DELAY REJECTION FUSE

Mouse over image to zoom, click to enlarge

Description:
CLASS CC TIME DELAY REJECTION FUSE

UPC:  05171249710

Part Number: FNQ-R-12

UNSPSC: 39121606

Status:  UNKNOWN

Your Price:  $31.11 / EA


Quantity  EA

Specifications

Manufacturer Name BUSSMANN
MfgPartNo FNQ-R-12
Additional Information RoHS Compliant; Material Melamine (Tube); Application Branch Circuit, Line Protection, Small Control Transformers, Industrial Controls and Panels, Isolated, In-Line Fuse Holders
Amperage Rating 12 A
Application Ind Facilities & Factories - Facility: Safety and Security Systems
Approval UL 248-4, CSA, CE
Base Price 0.0000
Brand Name Eaton;Limitron
Catalog Number FNQ-R-12
Characteristics Time Delay
Class CC
Commerce Sector Construction Materials
Commodity Code 61200
Commodity Description Small Dimension Fuses
Connection Ferrule end x ferrule end
CountryOfOrigin MX
Current Rating 12 Amp
DDCATEGORY 281
Diameter 13/32 Inch
Dimensions 0.4100 IN X 0.4100 IN X 1.5000 IN
Directory CIS
Families 281
Family Description Small Dimension Fuses
Image Location * Image
Industry ELX
Interrupt Rating 200 kAIC
Interrupting Rating 200 Kiloamp (Symmetrical)
InvoiceDescription CLASS CC TIME DELAY REJECTION FUSE;600V MIDGET TD FUSE
Item Number 49710
Length 1-1/2 Inch
Long Description MIDGET FUSE, CLASS CC REJECTION TYPE; 1-1/2 INCH; UL 248-4, CSA, CE APPROVAL; 600 VOLT AC VOLTAGE RATING; 13/32 INCH DIAMETER; 200 KILOAMP (SYMMETRICAL) INTERRUPTING RATING; 12 AMP CURRENT RATING; FERRULE TERMINAL TYPE; TIME DELAY CHARACTERISTICS
MSDS Form Number *
Material Melamine tube
Model FNQ-R
Noun *
Product Description CLASS CC TIME DELAY REJECTION FUSE
Product Keywords WEBREADY
Product Name Cartridge fuses
ProductLine BUSS
Response Time 12 S at 200%
Size 13/32 In Diameter X 1-1/2 In Length
Special Features Rejection style
Standard RoHS Compliant,CE Marked
Sub Brand Bussmann Series
Terminal Type Ferrule
Type Fuse;Class CC Rejection
UNSPSC 39121606
UPC 05171249710
Vendor Name EATON BUSSMANN
Vendor Number 051712
Vendor Short Name BUSS
Voltage Rating 600 V;600 Volt AC

Resources

CatalogNumber FNQ-R-12
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
