| Manufacturer Name | BUSSMANN |
| MfgPartNo | FNQ-R-6-1/4 |
| Additional Information | RoHS Compliant; Material Melamine (Tube); Application Branch Circuit, Line Protection, Small Control Transformers, Industrial Controls and Panels, Isolated, In-Line Fuse Holders |
| Amperage Rating | 6.25A |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Approval | UL 248-4, CSA, CE |
| Base Price | 0.0000 |
| Brand Name | Eaton;Limitron[TM] |
| Catalog Number | FNQ-R-6-1/4 |
| Characteristics | Time Delay |
| Class | CC |
| Commerce Sector | Construction Materials |
| Commodity Code | 61200 |
| Commodity Description | Small Dimension Fuses |
| Connection | Ferrule end x ferrule end |
| CountryOfOrigin | MX |
| Current Rating | 6-1/4 Amp |
| DDCATEGORY | 281 |
| Diameter | 13/32 Inch |
| Dimensions | 0.4100 IN X 0.4100 IN X 1.5000 IN |
| Directory | CIS |
| Families | 281 |
| Family Description | Small Dimension Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 200 kAIC |
| Interrupting Rating | 200 Kiloamp (Symmetrical) |
| InvoiceDescription | CLASS CC TIME DELAY;600V MIDGET TD FUS |
| Item Number | 49701 |
| Length | 1-1/2 Inch |
| Long Description | MIDGET FUSE, CLASS CC REJECTION TYPE; 1-1/2 INCH; UL 248-4, CSA, CE APPROVAL; 600 VOLT AC VOLTAGE RATING; 13/32 INCH DIAMETER; 200 KILOAMP (SYMMETRICAL) INTERRUPTING RATING; 6-1/4 AMP CURRENT RATING; FERRULE TERMINAL TYPE; TIME DELAY CHARACTERISTICS |
| MSDS Form Number | * |
| Material | Melamine tube |
| Model | FNQ-R |
| Noun | * |
| Product Description | CLASS CC TIME DELAY |
| Product Keywords | WEBREADY |
| Product Name | Cartridge fuses |
| ProductLine | BUSS |
| Response Time | 12 S at 200% |
| Size | 13/32 In Diameter X 1-1/2 In Length |
| Special Features | Rejection style |
| Standard | CE Marked,RoHS Compliant |
| Sub Brand | Bussmann Series |
| Terminal Type | Ferrule |
| Type | Fuse;Class CC Rejection |
| UNSPSC | 39121606 |
| UPC | 05171249701 |
| Vendor Name | EATON BUSSMANN |
| Vendor Number | 051712 |
| Vendor Short Name | BUSS |
| Voltage Rating | 600 V;600 Volt AC |
