| Manufacturer Name | BUSSMANN |
| MfgPartNo | GMA-1-R |
| Additional Information | RoHS Compliant; Endcap Material Nickel Plated Brass; Application Electronic Circuit |
| Amperage Rating | 1 A |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Approval | UL 248-14, CSA, CE, PSE |
| Base Price | 0.0000 |
| Brand Name | Eaton |
| Catalog Number | GMA-1-R |
| Characteristics | Fast Acting |
| Commerce Sector | Construction Materials |
| Commodity Code | 61200 |
| Commodity Description | Small Dimension Fuses |
| Connection | Ferrule end x ferrule end |
| CountryOfOrigin | CN |
| Current Rating | 1 Amp |
| DDCATEGORY | 281 |
| Diameter | 5 Millimeter |
| Dimensions | 0.7874 IN X 0.1969 IN X 0.1969 IN |
| Directory | CIS |
| Families | 281 |
| Family Description | Small Dimension Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 35 AIC at 250 Vac10 kAIC at 125 Vac |
| Interrupting Rating | 35 Amp at 250 Volt AC, 10000 Amp at 125 Volt AC |
| InvoiceDescription | GMA 1A BUSS FUSE;MINIATURE FUSE |
| Item Number | 64783 |
| Length | 20 Millimeter |
| Long Description | FUSE, GLASS TUBE TYPE; 20 MILLIMETER; UL 248-14, CSA, CE, PSE APPROVAL; 250 VOLT AC VOLTAGE RATING; 5 MILLIMETER DIAMETER; 35 AMP AT 250 VOLT AC, 10000 AMP AT 125 VOLT AC INTERRUPTING RATING; 1 AMP CURRENT RATING; FERRULE TERMINAL TYPE |
| MSDS Form Number | * |
| Material | Nickel-plated brass endcapsGlass tube |
| Model | GMA |
| Noun | * |
| Product Description | GMA 1A BUSS FUSE |
| Product Keywords | WEBREADY |
| Product Name | Midget fuses |
| ProductLine | BUSS |
| Response Time | 60 min at 135%, 2 min at 200% |
| Size | 5 mm Diameter X 20 mm Length |
| Special Features | Low Breaking Capacity, Interrupt Rating 35 Amp at 250 Vac, 10 kA at 125 Vac, Material Glass Tube, Nickel Plated Brass Endcap, ROHS Complaint |
| Standard | RoHS Compliant,CE Marked |
| Sub Brand | Bussmann Series |
| Terminal Type | Ferrule |
| Type | Fast-acting fuse;Glass Tube |
| UNSPSC | 39121609 |
| UPC | 05171264783 |
| Vendor Name | EATON BUSSMANN |
| Vendor Number | 051712 |
| Vendor Short Name | BUSS |
| Voltage Rating | 250 Vac, 32 Vdc (self certified);250 Volt AC |
