| Manufacturer Name | BUSSMANN |
| MfgPartNo | LP-CC-2-1/4 |
| Additional Information | Material Melamine (Tube); Application Branch Circuit Protection, Specialized Circuit, Industrial Control and Panel, Isolated In-Line Fuse Holder |
| Amperage Rating | 2.25 A |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Approval | UL 248-4, CSA, CE |
| Base Price | 0.0000 |
| Brand Name | Eaton;Low-Peak[TM] |
| Catalog Number | LP-CC-2-1/4 |
| Characteristics | Time Delay, Current Limiting, Dual Element |
| Class | CC |
| Commerce Sector | Construction Materials |
| Commodity Code | 61130 |
| Commodity Description | Current Limiting Fuses |
| Connection | Ferrule end x ferrule end |
| CountryOfOrigin | MUL |
| Current Rating | 2-1/4 Amp |
| DDCATEGORY | 582 |
| Diameter | 13/32 Inch |
| Dimensions | 0.4100 IN X 0.4100 IN X 1.5000 IN |
| Directory | CIS |
| Element | Dual |
| Families | 582 |
| Family Description | Current Limiting Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 200 kAIC at 600 Vac20 kAIC at 300 Vdc |
| Interrupting Rating | 200 Kiloamp (Symmetrical), 20 Kiloamp (DC) |
| InvoiceDescription | LOW PEAK CC TIME DELAY;LW-PEAK CC TD FUSE |
| Item Number | 18050 |
| Length | 1-1/2 Inch |
| Long Description | MIDGET FUSE, CLASS CC REJECTION TYPE; 1-1/2 INCH; UL 248-4, CSA, CE APPROVAL; 600 VOLT AC, 300 VOLT DC VOLTAGE RATING; 13/32 INCH DIAMETER; 200 KILOAMP (SYMMETRICAL), 20 KILOAMP (DC) INTERRUPTING RATING; 2-1/4 AMP CURRENT RATING; FERRULE TERMINAL TYPE |
| MSDS Form Number | * |
| Material | Melamine tube |
| Model | LP-CC |
| Noun | * |
| Product Description | LOW PEAK CC TIME DELAY |
| Product Keywords | WEBREADY |
| Product Name | Cartridge fuses |
| ProductLine | BUSS |
| Response Time | 12 S at 200% |
| Size | 13/32 In Diameter X 1-1/2 In Length |
| Special Features | Rejection style |
| Standard | CE Marked,RoHS Compliant |
| Sub Brand | Bussmann Series |
| Terminal Type | Ferrule |
| Type | Fuse;Class CC Rejection |
| UNSPSC | 39121606 |
| UPC | 05171218050 |
| Vendor Name | EATON BUSSMANN |
| Vendor Number | 051712 |
| Vendor Short Name | BUSS |
| Voltage Rating | 600//300 VAC//VDC;600 Volt AC, 300 Volt DC |
