BUSS RD100-3

Switch 100A Non-F 3P UL98

Page Loading...
BUSSMANN
Switch 100A Non-F 3P UL98

Mouse over image to zoom, click to enlarge

Description:
Switch 100A Non-F 3P UL98

UPC:  05171240241

Part Number: RD100-3

UNSPSC: 39122205

Status:  UNKNOWN

Retail Price:  $712.60 / EA
Your Price:  $327.07 / EA


Quantity  EA

Specifications

Manufacturer Name BUSSMANN
MfgPartNo RD100-3
Additional Information RoHS Compliant; Short Circuit Current Rating 100 Kiloamp at 480 Volt AC, 25 Kiloamp at 600 Volt AC; Temperature Rating -20 to 70 Deg C
Amperage Rating 100 A
Application Stationary Mach Equip In Factory - Robotics
Approval UL, CSA 22.2, CE
Base Price 0.0000
Brand Name Eaton
Catalog Number RD100-3
Commerce Sector Construction Materials
Commodity Code 31820
Commodity Description Non-Fusible Rotary Safety Switches
Conductor Material Copper
Conductor Size 10 to 1 AWG, 1/0 AWG, 2/0 AWG (Stranded), 12 to 10 AWG (Solid)
CountryOfOrigin MUL
Current Rating 100 Amp
DDCATEGORY 1722
Dimensions 8.0000 IN X 6.0000 IN X 14.0000 IN
Directory CIS
Families 1722
Family Description Non-Fusible Rotary Safety Switches
Fuse Type Class J
Image Location * Image
Industry ELX
InvoiceDescription Switch 100A Non-F 3P UL98;3P 100A DIS-SW
Item Number 40241
Long Description ROTARY DISCONNECT SWITCH, NON-FUSIBLE, COMPACT TYPE; COPPER CONDUCTOR MATERIAL; UL, CSA 22.2, CE APPROVAL; 120/240/480/600 VOLT AC (UL 98) VOLTAGE RATING; DIN-RAIL/PANEL MOUNTING; 100 AMP CURRENT RATING
MSDS Form Number *
Model RD
Mounting DIN-Rail/Panel
Noun *
Number Of Poles 3
Operating Temperature 70 CEL
Operator Position Front/Side
Operator Type Direct Handle, Shaft
Power Rating 5 HP at 120 Volt AC 1-Phase, 10 HP at 240 Volt AC 1-Phase, 20 HP at 240 Volt AC 3-Phase, 50 HP at 480/600 Volt AC 3-Phase
Product Description Switch 100A Non-F 3P UL98
Product Keywords WEBREADY
Product Name Safety switch
ProductLine BUSS
Special Features Compact switch, Front/side handle operation
Standard Not Applicable,RoHS Compliant
Sub Brand Bussmann Series
Terminal Type Lug
Type Non-fused disconnect switch;Non-Fusible, Compact
UNSPSC 39122205
UPC 05171240241
Vendor Name EATON BUSSMANN
Vendor Number 051712
Vendor Short Name BUSS
Voltage Rating 600 V;120/240/480/600 Volt AC (UL 98)

Resources

CatalogNumber RD100-3
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
