| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | 10250T181HRG |
| Actuator | Standard |
| Additional Information | ENVIRONMENTAL CONDITIONS OIL TIGHT, WATER TIGHT; HEAVY DUTY; OPERATING TEMPERATURE 32 TO 140 DEG F; TERMINAL TYPE SADDLE CLAMP |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsCommercial / Institutional Buildings / Structures - Power Distribution and Controls |
| Approval | UL 508, UL 1604, CSA C22.2, CE EN 60947-5-1/10.91 |
| Base Price | 0.0000 |
| Body Material | CHROME PLATED DIE CAST ZINC |
| Catalog Number | 10250T181HRG |
| Commerce Sector | Construction Materials |
| Commodity Code | 42230 |
| Commodity Description | Pilot Light Complete Assemblies |
| CountryOfOrigin | US |
| DDCATEGORY | 2154 |
| Depth | 0.01 in |
| Directory | CIS |
| Enclosure | NEMA 3/3R/3S/4/4X/12/13, NEC CLASS I DIV 2, IP65 |
| Families | 2154 |
| Family Description | Pilot Light Complete Assemblies |
| Height | 0.01 in |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | IND LGT 120V/XFR RD GLASS LENS-CL I DIV2;120V RED IND LIGHT |
| Item Number | 51641 |
| Lamp Input Type | 120 VAC TRANSFORMER |
| Lamp Number | 755 |
| Lamp Type | INCANDESCENT |
| Lens Color | RED |
| Lens Material | GLASS |
| Lens Style Size | ROUND |
| Long Description | INDICATING LIGHT, STANDARD TYPE; 30.5 MM SIZE; UL 508, UL 1604, CSA C22.2, CE EN 60947-5-1/10.91 APPROVAL; NEMA 3/3R/3S/4/4X/12/13, NEC CLASS I DIV 2, IP65 ENCLOSURE; CHROME PLATED DIE CAST ZINC BODY MATERIAL; INCANDESCENT LAMP TYPE |
| MSDS Form Number | * |
| Model | Pushbutton;10250T |
| Noun | * |
| Product Description | 120V RED IND LIGHT |
| Product Keywords | WEBREADY |
| Product Name | Push button switch |
| ProductLine | C-H |
| Size | 30.5 MM |
| Standard | UL Listed,CSA Certified,CE Marked |
| Type | STANDARD |
| UNSPSC | 39122216 |
| UPC | 78211451641 |
| Vendor Name | EATON CONTROLS/DISTRIBUTION EQUIPMENT |
| Vendor Number | 782114 |
| Vendor Short Name | CH1 |
| Width | 0.01 in |
