| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | 10250T3593 |
| Action | Green, red |
| Actuator | 1 indicating light, 2 pushbuttons (1 flush, 1 extended) |
| Additional Information | INDUSTRIAL GRADE; OPERATING TEMPERATURE RANGE 1 TO 150 DEG F; OPERATOR SIZE 30.5 MM; TRANSFORMER TYPE INDICATING LIGHT |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs |
| Base Price | 0.0000 |
| Cable Conduit Entry | 1 INCH NPT KNOCKOUT |
| Catalog Number | 10250T3593 |
| Commerce Sector | Construction Materials |
| Commodity Code | 42310 |
| Commodity Description | Control Station Complete Assemblies |
| Contact Configuration | 1 NO-2 NC;1NO-2NC |
| CountryOfOrigin | DO |
| DDCATEGORY | 2161 |
| Depth | 0.25 in |
| Directory | CIS |
| Enclosure | NEMA 4/4X/12/13 |
| Families | 2161 |
| Family Description | Control Station Complete Assemblies |
| Finish | GRAY |
| Height | 7.75 in |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | OILTIGHT PUSHBUTTON STATION;30.5MM CNTL STA |
| Item Number | 45806 |
| Legend | START/STOP/MOTOR RUN |
| Long Description | PUSH BUTTON CONTROL STATION, PUSHBUTTON/INDICATING LIGHT TYPE; DIE CAST ZINC MATERIAL; 3.75 INCH W X 0.13 INCH D X 1.94 INCH H SIZE; GRAY FINISH; 1NO-2NC CONTACT CONFIGURATION; FLUSH MOUNTING; NEMA 4/4X/12/13 ENCLOSURE; START/STOP/MOTOR RUN LEGEND |
| MSDS Form Number | * |
| Material | Die cast;DIE CAST ZINC |
| Model | Pushbutton;10250T |
| Mounting | FLUSH |
| Noun | * |
| Number Of Elements | 3 |
| Operator Color | BLACK, RED, RED LENS |
| Operator Type | (2) FLUSH ROUND, (1) INDICATION LIGHT 110 V |
| Product Description | 30.5MM CNTL STA |
| Product Keywords | WEBREADY |
| Product Name | Push button switch |
| ProductLine | C-H |
| Size | 3.75 INCH W X 0.13 INCH D X 1.94 INCH H |
| Standard | CSA Certified,UL Listed,CE Marked |
| Type | PUSHBUTTON/INDICATING LIGHT |
| UNSPSC | 39122216 |
| UPC | 78211345806 |
| Vendor Name | EATON DISTRIBUTION EQUIPMENT/CONTROLS |
| Vendor Number | 782113 |
| Vendor Short Name | CH3 |
| Width | 3.88 in |
