| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | 10316H1002 |
| Actuator Head Type | Side Rotary |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs |
| Approval | UL (Canada and US), CUL |
| Body Material | Silicon Bronze |
| Catalog Number | 10316H1002 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46140 |
| Commodity Description | Severe Duty Limit Switches |
| Connection | Screw terminal |
| Connection Type | Screw Terminal |
| Contact Configuration | 1 NO-1 NC;1NO-1NC |
| Contact Rating | 10A at 240 Vac, 0.1A at 250 Vac;240 Volt AC at 10 Amp, 250 Volt AC at 0.1 Amp |
| CountryOfOrigin | MX |
| DDCATEGORY | 2184 |
| Dimensions | 5.2100 IN X 2.8100 IN X 2.2600 IN |
| Directory | CIS |
| Enclosure | Class I Div 1 Group B C D, Class II Div 1 Group E F G, NEMA 7/9 |
| Families | 2184 |
| Family Description | Severe Duty Limit Switches |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 10316 Type LX Limit Switch;LIMIT SWITCH |
| Item Number | 23011 |
| Long Description | LIMIT SWITCH, HAZARDOUS LOCATION TYPE; 1NO-1NC CONTACT CONFIGURATION; SCREW TERMINAL CONNECTION TYPE; SPRING RETURN, CLOCKWISE/COUNTERCLOCKWISE OPERATION TYPE; 240 VOLT AC AT 10 AMP, 250 VOLT AC AT 0.1 AMP CONTACT RATING; UL (CANADA AND US), CUL APPROVAL |
| MSDS Form Number | * |
| Model | 10316H, LX |
| Noun | * |
| Operating Force | 3 Inch-Pound |
| Operating Temperature | -20 to 200 Deg F |
| Operating Temperature Maximum | -20 F |
| Operating Temperature Minimum | -20 F |
| Operating Travel | 10 Degree |
| Operation Type | Spring Return, Clockwise/Counterclockwise |
| Pretravel | 10 Degree |
| Product Description | LIMIT SWITCH |
| Product Keywords | WEBREADY |
| Product Name | Limit switch |
| ProductLine | C-H |
| Reset Travel | 4 Degree |
| Standard | CSA Certified,UL Listed |
| Total Travel | 50 Degree |
| Type | Hazardous location limit switch;Hazardous Location |
| UNSPSC | 39122213 |
| UPC | 78211323011 |
| Vendor Name | EATON DISTRIBUTION EQUIPMENT/CONTROLS |
| Vendor Number | 782113 |
| Vendor Short Name | CH3 |
