| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | 10316H283 |
| Actuator Head Type | Top Push Roller |
| Additional Information | Enclosure Material Die-Cast Zinc |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand Name | Eaton |
| Catalog Number | 10316H283 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46140 |
| Commodity Description | Severe Duty Limit Switches |
| Connection | Screw terminal |
| Connection Type | Screw Terminal |
| Contact Configuration | 1 NO-1 NC;1NO-1NC |
| Contact Rating | 10A at 600Vac, 0.22A at 125Vdc;600 VAC at 10 Ampere, 125 VDC at 0.22 Ampere |
| CountryOfOrigin | MX |
| DDCATEGORY | 2184 |
| Dimensions | 1.5500 IN X 1.7800 IN X 4.8700 IN |
| Directory | CIS |
| Enclosure | NEMA 1/4/13 |
| Families | 2184 |
| Family Description | Severe Duty Limit Switches |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 10316 TYPE L LIMIT SWITCH;LIMIT SWITCH |
| Item Number | 20473 |
| Long Description | LIMIT SWITCH, STANDARD, NON-PLUG-IN TYPE; 1NO-1NC CONTACT CONFIGURATION; SCREW TERMINAL CONNECTION TYPE; SNAP OPERATION TYPE; 600 VAC AT 10 AMPERE, 125 VDC AT 0.22 AMPERE CONTACT RATING; UL, CSA APPROVAL; NEMA 1/4/13 ENCLOSURE |
| MSDS Form Number | * |
| Model | 10316H |
| Noun | * |
| Operating Force | 4 Lb |
| Operating Temperature | -20 FAH;-20 to 200 Deg F |
| Operating Travel | 0.04 Inch |
| Operation Type | Snap |
| Product Description | LIMIT SWITCH |
| Product Keywords | WEBREADY |
| Product Name | Limit switch |
| ProductLine | C-H |
| Reset Travel | 0.02 Inch |
| Standard | CSA Certified,UL Listed,Contact Manufacturer,CE Marked |
| Total Travel | 0.28 Inch |
| Type | Hazardous location limit switch;Standard, Non-Plug-In |
| UNSPSC | 39122213 |
| UPC | 78211320473 |
| Vendor Name | EATON DISTRIBUTION EQUIPMENT/CONTROLS |
| Vendor Number | 782113 |
| Vendor Short Name | CH3 |
