| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | C0200E2A |
| Additional Information | RoHS Compliant; Type Dry; Material Silicon Steel (Lamination), Copper (Coil); Includes Jumper, Fuse Clip |
| Applicable Standard | ANSI/NEMA-ST-1, IEEE |
| Application | Other |
| Approval | UL, UL (Canada and US), CSA, CUL |
| Base Price | 0.0000 |
| Catalog Number | C0200E2A |
| Commerce Sector | Construction Materials |
| Commodity Code | 39220 |
| Commodity Description | Encapsulated Industrial Control Transformers |
| CountryOfOrigin | US |
| DDCATEGORY | 2082 |
| Dimensions | 4.1800 IN X 4.5000 IN X 4.2200 IN |
| Directory | CIS |
| Families | 2082 |
| Family Description | Encapsulated Industrial Control Transformers |
| Frequency Rating | 50/60 Hertz |
| Image Location | * Image |
| Industry | ELX |
| Insulation Class | 130 |
| InvoiceDescription | 200 VA Type MTE Control Transformer;200VA TFMR |
| Item Number | 42260 |
| KVA Rating | 200 VA |
| Long Description | INDUSTRIAL CONTROL TRANSFORMER, 4.5 INCH WIDTH X 4.37 INCH DEPTH X 4.4 INCH HEIGHT SIZE; 50/60 HERTZ FREQUENCY RATING; UL, UL (CANADA AND US), CSA, CUL APPROVAL; ANSI/NEMA-ST-1, IEEE APPLICABLE STANDARD; 200 VOLT AMP POWER RATING; SCREW TERMINAL TYPE |
| MSDS Form Number | * |
| Model | C0 |
| Noun | * |
| Power Rating | 200 Volt Amp |
| Primary Voltage | 220 x 440 V, 230 x 460 V, 240 x 480 V;240 x 480 Volt AC, 230 x 460 Volt AC, 220 x 440 Volt AC |
| Product Description | 200VA TFMR |
| Product Keywords | WEBREADY |
| Product Name | Control power transformer |
| ProductLine | C-H |
| Secondary Voltage | 120/115/110 V;120/115/110 Volt AC |
| Size | 4.5 Inch Width x 4.37 Inch Depth x 4.4 Inch Height |
| Special Features | Primary Fuse Block |
| Standard | CSA Certified,UL Listed,cUL Certified,RoHS Compliant |
| Tap Size | None |
| Temperature Rating | 55C |
| Temperature Rise | 55 Deg C |
| Terminal Type | Screw |
| Type | Industrial control transformer |
| UNSPSC | 39121026 |
| UPC | 78668042260 |
| Vendor Name | EATON TFMRS & DISTRIB |
| Vendor Number | 786680 |
| Vendor Short Name | CHX |
