| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | CH8L125RP |
| Additional Information | Applicable Standard NEC |
| Amperage Rating | 125 A |
| Application | Ind Facilities & Factories - Facility: Power Distribution and Control |
| Approval | UL |
| Base Price | 0.0000 |
| Brand Name | Eaton |
| Breaker Mounting | Plug-On |
| Bus Material | Silver Flash Plated Copper |
| Catalog Number | CH8L125RP |
| Circuit Configuration | 1-Phase 3-Wire |
| Commerce Sector | Construction Materials |
| Commodity Code | 33110 |
| Commodity Description | Single Phase Main Lug Load Centers |
| CountryOfOrigin | US |
| Current Rating | 125 Amp |
| DDCATEGORY | 1852 |
| Dimensions | 13.0000 IN X 11.0000 IN X 3.6900 IN |
| Directory | CIS |
| Enclosure Size Designation | 7R |
| Enclosure Type | NEMA 3R, Outdoor, Rainproof |
| Families | 1852 |
| Family Description | Single Phase Main Lug Load Centers |
| Feed Location | Top/Bottom |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 25 kAIC |
| Interrupting Rating | 10 Kiloamp |
| InvoiceDescription | Eaton CH main lug loadcenter;1PH 125A LD-CTR |
| Item Number | 19054 |
| Long Description | MAIN LUG LOAD CENTER, MAIN LUG TYPE; 11 INCH WIDTH X 3.69 INCH DEPTH X 13 INCH HEIGHT SIZE; 16 MAX. NUMBER OF CIRCUITS; (8) 3/4 INCH MAX. NUMBER OF SPACES; UL APPROVAL; 120/240 VOLT AC VOLTAGE RATING; 10 KILOAMP INTERRUPTING RATING |
| MSDS Form Number | * |
| Main Breaker Type | CH |
| Main Wire Size | 6 to 1/0 AWG (Copper/Aluminum) |
| Maximum Number Of Circuits | 16 |
| Maximum Number Of Spaces | (8) 3/4 Inch |
| Model | CH |
| Neutral Type | Insulated/Bondable Single |
| Noun | * |
| Number Of Spaces | 8 |
| Phase | 1 |
| Product Description | 1PH 125A LD-CTR |
| Product Keywords | WEBREADY |
| Product Name | Load centers |
| ProductLine | C-H |
| Size | 7R;11 Inch Width x 3.69 Inch Depth x 13 Inch Height |
| Special Features | Cover included |
| Standard | UL 67,UL 50 |
| Type | Main lug loadcenter;Main Lug |
| UNSPSC | 39121101 |
| UPC | 78211419054 |
| Vendor Name | EATON CONTROLS/DISTRIBUTION EQUIPMENT |
| Vendor Number | 782114 |
| Vendor Short Name | CH1 |
| Voltage Rating | 120/240V, 208Y/120, 240V;120/240 Volt AC |
