| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | CHSPT2ULTRA |
| Additional Information | Operating Voltage Rating 150 Volt AC (L-N), 300 Volt AC (L-L) |
| Application | OtherResidential Bldgs & Facilities - Residential Bldgs & Facilities - Other |
| Approval | UL 1449, CUL |
| Base Price | 0.0000 |
| Catalog Number | CHSPT2ULTRA |
| Circuit Configuration | 1-Phase |
| Commerce Sector | Construction Materials |
| Commodity Code | 57430 |
| Commodity Description | Surge Suprsr-Prot Dev-Line Conditnr |
| CountryOfOrigin | CN |
| DDCATEGORY | 1170 |
| Depth | 7 in |
| Dimensions | 7.0000 IN X 5.0000 IN X 2.5000 IN |
| Directory | CIS |
| Enclosure | NEMA 4 |
| Families | 1170 |
| Family Description | Surge Suprsr-Prot Dev-Line Conditnr |
| Frequency Rating | 60 Hertz |
| Frequency Rating Maximum | 60 Hz |
| Frequency Rating Minimum | 60 Hz |
| Height | 2.5 in |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 1PH; UL1449 3RD EDITION; TYPE 2 SPD;1PH SPDEV |
| Item Number | 43688 |
| Long Description | SURGE PROTECTION DEVICE, 5 INCH WIDTH X 2.5 INCH DEPTH X 7 INCH HEIGHT SIZE; SERVICE ENTRANCE USED ON; 60 HERTZ FREQUENCY RATING; UL 1449, CUL APPROVAL; 120/240 VOLT AC VOLTAGE RATING; NEMA 4 ENCLOSURE; -40 TO 50 DEG C OPERATING TEMPERATURE |
| MSDS Form Number | * |
| Modes Of Protection | L-N, L-G, N-G, L-L |
| Noun | * |
| Operating Temperature | -40 to 50 Deg C |
| Operating Temperature Maximum | 122 F |
| Operating Temperature Minimum | -40 F |
| Phase | 1 |
| Product Description | 1PH SPDEV |
| Product Keywords | WEBREADY |
| Product Name | Lamp sockets |
| ProductLine | C-H |
| Short Circuit Rating | 22000 kA |
| Size | 5 Inch Width x 2.5 Inch Depth x 7 Inch Height |
| Special Features | Meets or exceeds the requirments specified in IBC 2006, CBC2007, and UBCZone 4 |
| Standard | UL 1449,cUL Certified,UL Recognized |
| Surge Current Per Phase | 108 Kiloamp |
| Type | Surge protection device |
| UNSPSC | 39111803 |
| UPC | 78668543688 |
| Used On | Service Entrance |
| Vendor Name | EATON NUMA-LOGIC CTRLS/DIST |
| Vendor Number | 786685 |
| Vendor Short Name | CHL |
| Voltage Rating | 120/240 V;120/240 Volt AC |
| Width | 5 in |
