| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | DT362URK |
| AC Voltage Rating | 600 V |
| Additional Information | Size 11.19 Inch x 11.95 Inch x 25.02 Inch; Used On Neutral, Ground Lug Kit; Double Throw |
| Amperage Rating | 60 A |
| Application | Commercial / Institutional Buildings / Structures - Power Distribution and Controls |
| Approval | UL |
| Base Price | 0.0000 |
| Catalog Number | DT362URK |
| Commerce Sector | Construction Materials |
| Commodity Code | 31420 |
| Commodity Description | Non-Fusible Double Throw Safety Switches |
| CountryOfOrigin | US |
| Current Rating | 60 Ampere |
| DC Voltage Rating | 250 V |
| DDCATEGORY | 1710 |
| Depth | 11.19 in |
| Directory | CIS |
| Enclosure | NEMA 3R |
| Enclosure Material | Steel |
| Families | 1710 |
| Family Description | Non-Fusible Double Throw Safety Switches |
| Finish | Painted, Galvanized |
| Fuse Provision | Non-Fusible |
| Height | 25.02 in |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 60A/3P HD NF DT Sw 600V N3R;3P 60A HD SFTY SW |
| Item Number | 42639 |
| Long Description | HEAVY DUTY SAFETY SWITCH, MANUAL, HEAVY DUTY TYPE; 11.94 INCH W X 9.88 INCH D X 24.63 INCH H SIZE; PAINTED, GALVANIZED FINISH; STEEL ENCLOSURE MATERIAL; 3 WIRE(S); UL APPROVAL; NEMA 3R ENCLOSURE; 60 AMPERE CURRENT RATING |
| MSDS Form Number | * |
| Material | Galvanized Steel |
| Model | DT |
| Neutral Type | No |
| Noun | * |
| Number Of Poles | 3 |
| Number Of Wires | 3 |
| Power Rating | 20 HP at 480 VAC 1-Phase, 25 HP at 600 VAC 1-Phase, 50 HP at 480 VAC 3-Phase, 10 HP at 250 VDC |
| Product Description | 3P 60A HD SFTY SW |
| Product Keywords | WEBREADY |
| Product Name | Safety switch |
| ProductLine | C-H |
| Size | 11.94 Inch W x 9.88 Inch D x 24.63 Inch H |
| Standard | UL Listed |
| Type | Double-throw non-fused safety switch;Manual, Heavy Duty |
| UNSPSC | 39122205 |
| UPC | 78211342639 |
| Vendor Name | EATON DISTRIBUTION EQUIPMENT/CONTROLS |
| Vendor Number | 782113 |
| Vendor Short Name | CH3 |
| Voltage Rating | 600 Vac, 250 Vdc |
| Width | 11.95 in |
