| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | E57LAL12T111E40 |
| Additional Information | SIZE 2.87 INCH L |
| Application | Stationary Mach Equip In Factory - Other Stationary Machinery and Equipment - In Factory |
| Approval | CUL, CE |
| Barrel Diameter | 12 MM |
| Base Price | 0.0000 |
| Body Material | 303 STAINLESS STEEL |
| Brand Name | EATON[R] |
| Catalog Number | E57LAL12T111E40 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46220 |
| Commodity Description | Inductive Proximity Sensor |
| Connection Type | 40 M CABLE |
| CountryOfOrigin | MX |
| DDCATEGORY | 2191 |
| Dimensions | 6.0000 IN X 5.0000 IN X 1.7500 IN |
| Directory | CIS |
| Enclosure | NEMA 4/4X/6/6P/12/13, IP67/IP69K |
| Families | 2191 |
| Family Description | Inductive Proximity Sensor |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 12MM STD IND PROX 3W DC PNP, 40M CABLE;12MM PRX SEN |
| Item Number | 89502 |
| Load Current | 500 MILLIAMPERE AT 6 TO 30 VDC |
| Long Description | INDUCTIVE PROXIMITY SENSOR, 40 M CABLE CONNECTION TYPE; 3 WIRE(S); CUL, CE APPROVAL; 6 TO 48 VDC OPERATING VOLTAGE; NEMA 4/4X/6/6P/12/13, IP67/IP69K ENCLOSURE; 303 STAINLESS STEEL BODY MATERIAL; -13 TO 158 DEG F OPERATING TEMPERATURE |
| MSDS Form Number | * |
| Model | E57 |
| Noun | * |
| Number Of Wires | 3 |
| Operating Temperature | -13 TO 158 DEG F |
| Operating Voltage | 6 TO 48 VDC |
| Output Configuration | NO, PNP |
| Product Description | 12MM PRX SEN |
| Product Keywords | WEBREADY |
| Product Name | Proximity switch |
| ProductLine | C-H |
| Sensing Distance | 4 MM |
| Sensing Position | END |
| Shielding Type | UNSHIELDED |
| Standard | UL Listed |
| Switching Frequency | 800 HZ |
| Type | Inductive proximity sensor |
| UNSPSC | 39122230 |
| UPC | 78668589502 |
| Vendor Name | EATON NUMA-LOGIC CTRLS/DIST |
| Vendor Number | 786685 |
| Vendor Short Name | CHL |
