| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | E57LAL30T111S4 |
| Additional Information | INCORPORATES TRANSIENT NOISE, POWER ON FALSE PULSE, LATCHING SHORT CIRCUIT, REVERSE POLARITY PROTECTION; SENSOR LENGTH 74.2 MM L |
| Application | Stationary Mach Equip In Factory - Other Stationary Machinery and Equipment - In Factory |
| Approval | UL, CSA |
| Barrel Diameter | 30 MM |
| Base Price | 0.0000 |
| Body Material | 303 STAINLESS STEEL |
| Catalog Number | E57LAL30T111S4 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46220 |
| Commodity Description | Inductive Proximity Sensor |
| Connection Type | 4 M CABLE |
| Construction | SMOOTH BARREL |
| CountryOfOrigin | MX |
| DDCATEGORY | 2191 |
| Dimensions | 1.1800 IN X 1.1800 IN X 2.7300 IN |
| Directory | CIS |
| Enclosure | NEMA 4/4X/6/6P/12/13, IP67 |
| Families | 2191 |
| Family Description | Inductive Proximity Sensor |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 30MM STD IND PROX 3W DC PNP 4M CABLE;30MM PRX SEN |
| Item Number | 98825 |
| Load Current | 200 MILLIAMPERE |
| Long Description | INDUCTIVE PROXIMITY SENSOR, 4 M CABLE CONNECTION TYPE; 3 WIRE(S); UL, CSA APPROVAL; 10 TO 50 VDC OPERATING VOLTAGE; NEMA 4/4X/6/6P/12/13, IP67 ENCLOSURE; 303 STAINLESS STEEL BODY MATERIAL; SMOOTH BARREL CONSTRUCTION |
| MSDS Form Number | * |
| Model | E57 |
| Noun | * |
| Number Of Wires | 3 |
| Operating Temperature | -13 TO 158 DEG F |
| Operating Voltage | 10 TO 50 VDC |
| Output Configuration | NO, PNP |
| Product Description | 30MM PRX SEN |
| Product Keywords | WEBREADY |
| Product Name | Proximity switch |
| ProductLine | C-H |
| Sensing Distance | 10 MM |
| Sensing Position | END |
| Shielding Type | SHIELDED |
| Standard | UL Listed,CSA Certified,CE Marked |
| Switching Frequency | 300 HZ |
| Type | Inductive proximity sensor |
| UNSPSC | 39122230 |
| UPC | 78211398825 |
| Vendor Name | EATON DISTRIBUTION EQUIPMENT/CONTROLS |
| Vendor Number | 782113 |
| Vendor Short Name | CH3 |
