| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | E59-M18C118A01-A1 |
| Accuracy | < 3% sensing range |
| Application | Stationary Mach Equip In Factory - Other Stationary Machinery and Equipment - In Factory |
| Approval | CUL |
| Barrel Diameter | 18 MM |
| Base Price | 0.0000 |
| Body Material | 303 STAINLESS STEEL |
| Brand Name | iProx[T], Cutler-Hammer[R] |
| Catalog Number | E59-M18C118A01-A1 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46220 |
| Commodity Description | Inductive Proximity Sensor |
| Connection | Dual key micro |
| Connection Type | 3 PIN MICRO AC CONNECTOR |
| Construction | THREADED BARREL |
| CountryOfOrigin | MX |
| DDCATEGORY | 2191 |
| Depth | 18 |
| Dimensions | 2.7300 IN X 0.7100 IN X 0.7100 IN |
| Directory | CIS |
| Enclosure | NEMA 4/4X/6/6P/12/13, IP67 |
| Environmental Conditions | NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67, IP69K |
| Families | 2191 |
| Family Description | Inductive Proximity Sensor |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 18MM IPROX CLONE,AC,UNS 18MM SN,NO MICRO;18MM PROX SEN;18MM SEN |
| Item Number | 18349 |
| Load Current | 200 MILLIAMPERE |
| Long Description | INDUCTIVE PROXIMITY SENSOR, 3 PIN MICRO AC CONNECTOR CONNECTION TYPE; 2 WIRE(S); CUL APPROVAL; 20 TO 132 VAC OPERATING VOLTAGE; NEMA 4/4X/6/6P/12/13, IP67 ENCLOSURE; 303 STAINLESS STEEL BODY MATERIAL; THREADED BARREL CONSTRUCTION |
| MSDS Form Number | * |
| Model | E59 |
| Noun | * |
| Number Of Wires | 2 |
| Operating Temperature | -40 TO 158 DEG F |
| Operating Voltage | 20 TO 132 VAC |
| Output Configuration | NO |
| Product Description | 18MM SEN |
| Product Keywords | WEBREADY |
| Product Name | Proximity sensors |
| ProductLine | C-H |
| Sensing Distance | 18 MM |
| Sensing Position | END |
| Shielding Type | UNSHIELDED |
| Standard | CSA Certified,UL Listed,CE Marked |
| Temperature Rating Maximum | -40 F |
| Temperature Rating Minimum | -40 F |
| Type | Programmable inductive proximity sensor |
| UNSPSC | 41111926 |
| UPC | 78211618349 |
| Vendor Name | EATON CONTROLS/MULTIPLE METERING |
| Vendor Number | 782116 |
| Vendor Short Name | CH2 |
