| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | FDB3015 |
| Additional Information | Applicable Standard NEMA AB1, AS 2184/3947-2, BS 4752, IEC 60947-2, SABS 156, SEV 947.2, VDE 0660 |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Catalog Number | FDB3015 |
| Circuit Breaker Frame | F |
| Commerce Sector | Construction Materials |
| Commodity Code | 32613 |
| Commodity Description | 3 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers |
| CountryOfOrigin | DO |
| Current Rating | 15 A;15 Amp at 40 Deg C |
| DDCATEGORY | 1806 |
| Dimensions | 3.3800 IN X 4.1300 IN X 6.0000 IN |
| Directory | CIS |
| Families | 1806 |
| Family Description | 3 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers |
| Frame | F |
| Frame Type | F |
| Frequency Rating Maximum | 60 Hz |
| Frequency Rating Minimum | 50 Hz |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating 240VAC | 18 kAIC at 240 Vac14 kAIC at 480 Vac |
| Interrupt Rating 480VAC | 14 |
| Interrupting Rating | 18 Kiloamp at 240 Volt AC, 14 Kiloamp at 480 Volt AC |
| InvoiceDescription | FDB 3P 15A TRIP 600V CL LOAD TERM ONLY;15A 3P CKT BREAKER |
| Item Number | 30582 |
| Long Description | MOLDED CASE THERMAL MAGNETIC CIRCUIT BREAKER, MOLDED CASE, FIXED THERMAL, FIXED MAGNETIC TYPE; 4.13 INCH WIDTH X 3.38 INCH DEPTH X 6 INCH HEIGHT SIZE; 600 VOLT MAX. AC VOLTAGE RATING; 250 VOLT MAX. DC VOLTAGE RATING; UL, CSA APPROVAL |
| MSDS Form Number | * |
| Maximum AC Voltage Rating | 600 Volt |
| Maximum DC Voltage Rating | 250 Volt |
| Noun | * |
| Number Of Poles | 3 |
| Product Description | 15A 3P CKT BREAKER |
| Product Keywords | WEBREADY |
| Product Name | Molded case circuit breakers |
| ProductLine | C-H |
| Size | 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height |
| Standard | UL Listed |
| Terminal Type | Load Side Lug |
| Tripping Characteristic | T186 |
| Type | Molded case circuit breaker;Molded Case, Fixed Thermal, Fixed Magnetic |
| UNSPSC | 39121616 |
| UPC | 78667930582 |
| Vendor Name | EATON METERING & DISTRIB |
| Vendor Number | 786679 |
| Vendor Short Name | CHD |
| Voltage Rating | 600 Vac, 250 Vdc;600 Volt AC 50/60 Hertz, 250 Volt DC |
