| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | HFD1050 |
| Additional Information | APPLICABLE STANDARD IEC 157-1 |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other |
| Approval | UL |
| Base Price | 0.0000 |
| Brand Name | Eaton |
| Catalog Number | HFD1050 |
| Commerce Sector | Construction Materials |
| Commodity Code | 32611 |
| Commodity Description | 1 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers |
| CountryOfOrigin | DO |
| Current Rating | 50 A;50 AMPERE AT 40 DEG C |
| DDCATEGORY | 1804 |
| Dimensions | 3.3800 IN X 1.3800 IN X 6.0000 IN |
| Directory | CIS |
| Families | 1804 |
| Family Description | 1 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers |
| Frame | F |
| Frame Type | F |
| Frequency Rating | 50/60 Hz |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 65 kAIC at 480 Vac100 kAIC at 240 Vac |
| Interrupting Rating | 65 KILOAMPERE AT 277 VAC, 10 KILOAMPERE AT 125 VDC (UL); 65 KILOAMPERE AT 220/240 VAC, 10 KILOAMPERE AT 125 VDC (IEC) |
| InvoiceDescription | HFD 1P 50A BKR;1P 50A CB |
| Item Number | 17531 |
| Long Description | MOLDED CASE CIRCUIT BREAKER, MOLDED CASE, THERMAL MAGNETIC TYPE; 1.375 INCH W X 3.375 INCH D X 6 INCH H SIZE; 277 MAX. AC VOLTAGE RATING; 125 MAX. DC VOLTAGE RATING; UL APPROVAL; 277 VAC AT 50/60 HZ, 125 VDC VOLTAGE RATING |
| MSDS Form Number | * |
| Maximum AC Voltage Rating | 277 |
| Maximum AC Voltage Rating UOM | V |
| Maximum DC Voltage Rating | 125 |
| Maximum DC Voltage Rating UOM | V |
| Model | HFD |
| Noun | * |
| Number Of Poles | 1 |
| Product Description | 1P 50A CB |
| Product Keywords | WEBREADY |
| Product Name | Molded case circuit breakers |
| ProductLine | C-H |
| Size | 1.375 INCH W X 3.375 INCH D X 6 INCH H |
| Standard | UL Listed |
| Terminal Type | STANDARD PRESSURE LOAD TERMINAL |
| Trip Type | Fixed thermal, fixed magnetic |
| Type | Molded case circuit breaker;MOLDED CASE, THERMAL MAGNETIC |
| UNSPSC | 39121616 |
| UPC | 78667917531 |
| Vendor Name | EATON METERING & DISTRIB |
| Vendor Number | 786679 |
| Vendor Short Name | CHD |
| Voltage Rating | 347//125 VAC//VDC;277 VAC AT 50/60 HZ, 125 VDC |
