| Manufacturer Name | EATON CONTROLS (CUTLER-HAMMER) |
| MfgPartNo | JD3250F |
| Accessory Type | Breaker Frame |
| Additional Information | Application Panelboard, Switchboard, Motor Control Center and Busway; Applicable Standard IEC 60947-2, NEMA AB1, AS 2184, BS 4752, SABS 156, SEV 157-1, VDE 0660, Federal Specification W-C375B |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs |
| Approval | UL 489 |
| Base Price | 0.0000 |
| Catalog Number | JD3250F |
| Circuit Breaker Frame | J |
| Commerce Sector | Construction Materials |
| Commodity Code | 32632 |
| Commodity Description | 3 Pole Interchangeable Trip Thermal Magnetic Cb Frames Only |
| CountryOfOrigin | DO |
| Current Rating | 250 A;250 Amp at 40 Deg C |
| DDCATEGORY | 1814 |
| Dimensions | 4.0600 IN X 4.1300 IN X 4.1300 IN |
| Directory | CIS |
| Families | 1814 |
| Family Description | 3 Pole Interchangeable Trip Thermal Magnetic Cb Frames Only |
| Frame | J |
| Frequency Rating Maximum | 60 Hz |
| Frequency Rating Minimum | 50 Hz |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating 240VAC | 65 kAIC at 240 Vac35 kAIC at 480 Vac |
| Interrupt Rating 480VAC | 35 |
| Interrupting Rating | 18 Kiloamp at 600 Volt AC, 10 Kiloamp at 250 Volt DC |
| InvoiceDescription | TYPE JD 3P INDUSTRIAL CIR BKR FRAME;3P FRAME |
| Item Number | 51637 |
| Long Description | THERMAL MAGNETIC CIRCUIT BREAKER FRAME, THERMAL MAGNETIC, JD FRAME TYPE; 4.13 INCH WIDTH X 4.06 INCH DEPTH X 10 INCH HEIGHT SIZE; 600 VOLT MAX. AC VOLTAGE RATING; UL 489 APPROVAL; 600 VOLT AC AT 50/60 HERTZ VOLTAGE RATING |
| MSDS Form Number | * |
| Maximum AC Voltage Rating | 600 Volt |
| Model | C, JD |
| Noun | * |
| Number Of Poles | 3 |
| Product Description | 3P FRAME |
| Product Keywords | WEBREADY |
| Product Name | Molded case circuit breakers |
| ProductLine | C-H |
| Size | 4.13 Inch Width x 4.06 Inch Depth x 10 Inch Height |
| Standard | UL Listed |
| Terminal Type | Not Included |
| Tripping Characteristic | T186 |
| Type | Molded case circuit breaker;Thermal Magnetic, JD Frame |
| UNSPSC | 39121616 |
| UPC | 78667951637 |
| Vendor Name | EATON METERING & DISTRIB |
| Vendor Number | 786679 |
| Vendor Short Name | CHD |
| Voltage Rating | 600 Vac, 250 Vdc;600 Volt AC at 50/60 Hertz |
