| Manufacturer Name | CROUSE-HINDS ECM & LTG |
| MfgPartNo | AFU0333 66 |
| Action | Snap action |
| Amperage Rating | 15 A |
| Application | Ind Facilities & Factories - Facility: Power Distribution and Control;Wet Location |
| Approval | UL 698, CSA 22.2 |
| Base Price | 0.0000 |
| Body Finish | Electrogalvanized Aluminum Acrylic Painted |
| Body Material | Feraloy Iron Alloy |
| Brand Name | Eaton |
| Cable Conduit Entry | (3) 1 Inch Hub |
| Catalog Number | AFU0333 66 |
| Commerce Sector | Construction Materials |
| Commodity Code | 47100 |
| Commodity Description | Cable Pull Switches & Accessories |
| Contact Configuration | Furnished with one or two end units, each containing 2-NO and 2-NC contact arrangements.;2NO-2NC (Each End) |
| CountryOfOrigin | US |
| Current Rating | 15 Ampere |
| DDCATEGORY | 2199 |
| Dimensions | 18.2800 IN X 9.5000 IN X 5.6800 IN |
| Directory | CIS |
| Enclosure | Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/4/9E/9F/9G, IP66 |
| Families | 2199 |
| Family Description | Cable Pull Switches & Accessories |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | AFU/AFUX EXPF SWITCH 600 VAC REPLACEMENT;CONVEYOR CONTROL |
| Item Number | 04709 |
| Long Description | STARTER CONTROL SWITCH, DOUBLE END TYPE; 18.28 INCH L X 9.5 INCH D X 4-15/16 INCH H SIZE; 25 LB MAX. UNSUPPORTED LINE WEIGHT; 2NO-2NC (EACH END) CONTACT CONFIGURATION; MAINTAINED OPERATION TYPE; UL 698, CSA 22.2 APPROVAL; WET LOCATION APPLICATION |
| MSDS Form Number | * |
| Material | Feraloy |
| Maximum Unsupported Line Weight | 25 Lb |
| Model | AFU |
| Mounting | (3) 1-1/2 Inch On-Center Lug |
| NEMA Rating | 349 |
| Noun | * |
| Operating Force | 50 Lb |
| Operation Type | Maintained |
| Operator Type | Plunger |
| Product Description | CONVEYOR CONTROL |
| Product Keywords | WEBREADY |
| Product Name | Safety switch |
| ProductLine | CRS-H |
| Size | 18.28 Inch L x 9.5 Inch D x 4-15/16 Inch H |
| Special Features | In installation, the actuating line or cable is connected from a fixed point to the loop on the end unit. A pull on the line of the required operating |
| Standard | Cl. II, Div. 1, Groups E, F, G, Cl. II, Div. 2, Groups F, G, Cl. III, \NEMA 3, 4, 7CD, 9EFG |
| Sub Brand | Crouse-Hinds series |
| Type | Conveyor belt control switch;Double End |
| UNSPSC | 39122205 |
| UPC | 78227404709 |
| Vendor Name | EATON CROUSE-HINDS INDUSTRIAL |
| Vendor Number | 782274 |
| Vendor Short Name | CRS-H |
| Voltage Rating | 600 VAC |
