| Manufacturer Name | CROUSE-HINDS ECM & LTG |
| MfgPartNo | EDS21273 |
| Additional Information | Application Hazardous Location, Wet Location |
| Application | Ind Facilities & Factories - Facility: Power Distribution and Control |
| Approval | UL 1203, CSA C22.2 |
| Base Price | 0.0000 |
| Box Type | Single Gang |
| Catalog Number | EDS21273 |
| Commerce Sector | Construction Materials |
| Commodity Code | 42250 |
| Commodity Description | Selector Switch Complete Assemblies |
| Constructional Feature | Explosionproof, Dust-Ignitionproof, Raintight |
| Contact Configuration | 4NO-2NC |
| CountryOfOrigin | MUL |
| DDCATEGORY | 2156 |
| Dimensions | 5.9000 IN X 3.5000 IN X 5.4400 IN |
| Directory | CIS |
| Enclosure | Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G;Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F9G |
| Enclosure Material | Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy |
| Families | 2156 |
| Family Description | Selector Switch Complete Assemblies |
| Hub Size | 3/4 Inch |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | EDS/EFD GENERAL USE SNAP SWITCHES;1G ENCL W/SW |
| Item Number | 76468 |
| Long Description | SELECTOR SWITCH, DEAD END TYPE; 4NO-2NC CONTACT CONFIGURATION; 3/4 INCH HUB SIZE; MAINTAINED OPERATION TYPE; ELECTROGALVANIZED ALUMINUM ACRYLIC PAINTED FERALOY IRON ALLOY ENCLOSURE MATERIAL; UL 1203, CSA C22.2 APPROVAL; 600 VAC VOLTAGE RATING |
| MSDS Form Number | * |
| Material | Feraloy iron alloy |
| Model | EDS |
| Noun | * |
| Number Of Circuits | 2 |
| Number Of Positions | 3 |
| Operation Type | Maintained |
| Operator Type | Knob |
| Product Description | 1G ENCL W/SW |
| Product Keywords | WEBREADY |
| Product Name | Rotary switch |
| ProductLine | CRS-H |
| Size | 5-7/8 In Length X 3-1/2 In Width X 3-1/16 In Height |
| Special Features | Single Gang, (3) Position (2) Circuit, Contact Configuration 4 No-2 Nc, 3/4 In Hub, Material Copper-Free Aluminum |
| Standard | UL 1203, CSA C22.2 |
| Type | Selector switch control station;Dead End |
| UNSPSC | 39122217 |
| UPC | 78227476468 |
| Vendor Name | EATON CROUSE-HINDS INDUSTRIAL |
| Vendor Number | 782274 |
| Vendor Short Name | CRS-H |
| Voltage Rating | 600 Vac;600 VAC |
