| Manufacturer Name | FEDERAL SIGNAL CORP. |
| MfgPartNo | 350TR-120 |
| Additional Information | Diaphragm Material Stainless Steel; Temperature Rating -65 to 150 Deg F |
| Application | Indoor/Outdoor;Industrial and Institutional Signaling, General Alarming, Start and Dismissal Noticing, Coded Paging and Process Control in Noisy Area |
| Approval | UL, CUL, CSA, FM |
| Base Price | 0.0000 |
| Brand Name | Federal Signal;Vibratone[R] |
| Catalog Number | 350TR-120 |
| Color | Gray |
| Commerce Sector | Construction Materials |
| Commodity Code | 63100 |
| Commodity Description | Bells,Horns,Sirens,Buzzers,Strobes |
| CountryOfOrigin | US |
| Current Rating | 0.18 Amp |
| DDCATEGORY | 591 |
| Dimensions | 5.61 H x 5.61 W x 2.30 D IN |
| Directory | CIS |
| Enclosure | Type 4X/Type 12;NEMA 4X/12 |
| Families | 591 |
| Family Description | Bells,Horns,Sirens,Buzzers,Strobes |
| Housing Material | Powder Coated Die-Cast Zinc |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | VIBRATONE HORN AND TRIM RING 120VAC;120V AC HORN&RING |
| Item Number | 21412 |
| Long Description | HORN AND TRIM RING, ELECTRO MECHANICAL VIBRATING HORN TYPE; 5.6 INCH WIDTH X 2.5 INCH DEPTH X 5.6 INCH HEIGHT SIZE; GRAY COLOR; UL, CUL, CSA, FM APPROVAL |
| Loudness | 100 DB |
| MSDS Form Number | * |
| Material | Zinc Die-Cast Housing |
| Model | 350 |
| Mounting | Surface |
| Noun | * |
| Operating Current | 0.18 A |
| Operating Temperature | -65 to 150 DEG F |
| Operating Voltage | 120VAC 50-60Hz |
| Product Description | 120V AC HORN&RING |
| Product Keywords | WEBREADY |
| Product Name | Safety horns |
| ProductLine | FED-SIG |
| Size | 5.6 Inch Width x 2.5 Inch Depth x 5.6 Inch Height |
| Sound Intensity | 100 Decibel at 10 Foot, 110 Decibel at 1 Meter |
| Special Features | Coded or Sustained Tones |
| Standard | UL Listed/cUL Listed |
| Sub Brand | Vibratone |
| Type | Horn;Electro Mechanical Vibrating Horn |
| UNSPSC | 46171602 |
| UPC | 78297921412 |
| Vendor Name | FEDERAL SIGNAL CORP. |
| Vendor Number | 782979 |
| Vendor Short Name | FED-SIG |
| Voltage Rating | 120 Volt AC at 50/60 Hertz |
