| Manufacturer Name | GE DIST/INDUSTRIAL |
| MfgPartNo | THQL2125HID |
| Additional Information | Trip Function LI; Application HACR, High Intensity Discharge Lighting |
| Amperage Rating | 25 A |
| Application | High Intensity Discharge Lighting |
| Approval | UL |
| Base Price | 0.0000 |
| Catalog Number | THQL2125HID |
| Commerce Sector | Construction Materials |
| Commodity Code | 32152 |
| Commodity Description | 2 Pole Special Application Plug-In Circuit Breakers |
| CountryOfOrigin | UKN |
| Current Rating | 25 Amp |
| DDCATEGORY | 1743 |
| Directory | CIS |
| Families | 1743 |
| Family Description | 2 Pole Special Application Plug-In Circuit Breakers |
| Frame | Q-Line |
| Frame Type | Q-Line |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 10kA@120 Vac / 10kA@120/240 Vac |
| Interrupting Rating | 10 Kiloamp at 120/240 Volt AC |
| InvoiceDescription | CIRCUIT BREAKER 2P 25A;2P25A 120/240 CB |
| Item Number | 16011 |
| Load Rating | HACR |
| Long Description | SPECIAL PURPOSE CIRCUIT BREAKER, 240 VOLT MAX. AC VOLTAGE RATING; UL APPROVAL; 120/240 VOLT AC VOLTAGE RATING; 10 KILOAMP AT 120/240 VOLT AC INTERRUPTING RATING; 25 AMP CURRENT RATING; 2 POLE(S); PLUG-IN TERMINAL TYPE; Q-LINE FRAME TYPE; TRIP FUNCTION LI |
| MSDS Form Number | * |
| Maximum AC Voltage Rating | 240 Volt |
| Noun | * |
| Number Of Poles | 2 |
| Product Description | 2P25A 120/240 CB |
| Product Keywords | WEBREADY |
| Product Name | Electrical boxes |
| ProductLine | GE |
| Special Features | HID breakers have been designed to handle the current and voltage spikes that result when gaseous discharge lamps, including fluorescent and HID lamps, are switched on and off. The THQL2125HID breaker features 2 poles, an ampere rating of 25 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V. |
| Standard | E11592 |
| Terminal Type | Plug-In |
| Trip Range Maximum | Non-Interchangeable |
| Trip Range Minimum | Non-Interchangeable |
| Trip Type | LI |
| UNSPSC | 39121303 |
| UPC | 78316416011 |
| Vendor Name | ABB DISTRIBUTION EQUIPMENT |
| Vendor Number | 783164 |
| Vendor Short Name | GE |
| Voltage Rating | 120/240 V;120/240 Volt AC |
