| Manufacturer Name | GE DIST/INDUSTRIAL |
| MfgPartNo | THQL31WY30 |
| Additional Information | Trip Function LI |
| Amperage Rating | 30 A |
| Application | Switching Neutral |
| Approval | UL |
| Base Price | 0.0000 |
| Catalog Number | THQL31WY30 |
| Commerce Sector | Construction Materials |
| Commodity Code | 32152 |
| Commodity Description | 2 Pole Special Application Plug-In Circuit Breakers |
| CountryOfOrigin | UKN |
| Current Rating | 30 Amp |
| DDCATEGORY | 1743 |
| Directory | CIS |
| Families | 1743 |
| Family Description | 2 Pole Special Application Plug-In Circuit Breakers |
| Frame | Q-Line |
| Frame Type | Q-Line |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 10kA@120 Vac / 10kA@120/240 Vac / 10kA@240 Vac |
| Interrupting Rating | 10 Kiloamp at 120/240 Volt AC |
| InvoiceDescription | CIRCUIT BREAKER 3P 30A 120/240V 10KA WY;120/240V-30A CB |
| Item Number | 12168 |
| Long Description | SPECIAL PURPOSE CIRCUIT BREAKER, 240 VOLT MAX. AC VOLTAGE RATING; UL APPROVAL; 120/240 VOLT AC VOLTAGE RATING; 10 KILOAMP AT 120/240 VOLT AC INTERRUPTING RATING; 30 AMP CURRENT RATING; 3 POLE(S); PLUG-IN TERMINAL TYPE; Q-LINE FRAME TYPE; TRIP FUNCTION LI |
| MSDS Form Number | * |
| Maximum AC Voltage Rating | 240 Volt |
| Noun | * |
| Number Of Poles | 3 |
| Product Description | 120/240V-30A CB |
| Product Keywords | WEBREADY |
| Product Name | Electrical boxes |
| ProductLine | GE |
| Special Features | A Molded Case Switch Breaker Is used to protect the circuit from being overwhelmed with large amounts of current. This could result in the breaker short circuiting or overloading. The THQL31WY30 breaker features 3 poles, an ampere rating of 30 A, an interrupting rating of 10kAIC, and a voltage rating of 240 V. |
| Standard | E11592 |
| Terminal Type | Plug-In |
| Trip Range Maximum | Non-Interchangeable |
| Trip Range Minimum | Non-Interchangeable |
| Trip Type | LI |
| UNSPSC | 39121303 |
| UPC | 78316412168 |
| Vendor Name | ABB DISTRIBUTION EQUIPMENT |
| Vendor Number | 783164 |
| Vendor Short Name | GE |
| Voltage Rating | 120/240 V;120/240 Volt AC |
