| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN10-24-480C |
| Additional Information | RoHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 3 x 0.8 or 2 x 1.2 |
| Application | Provides contact closure for remote monitoring of alarm conditions in you SolaHD UPS.;Industrial/Machine Control, Process Control, Conveying Equipment, Material Handling, Vending Machine, Packaging Equipment, Park Equipment, Semi-Conductor Fabrication Equipment |
| Approval | UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 16 - 10 AWG Solid |
| Catalog Number | SDN10-24-480C |
| Commerce Sector | Construction Materials |
| Commodity Code | 39610 |
| Commodity Description | Ac Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| Cooling Type | Convection |
| CountryOfOrigin | PH |
| DDCATEGORY | 2089 |
| Directory | CIS |
| Efficiency | 91.2;91.2 Percent |
| Enclosure | IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2089 |
| Family Description | Ac Power Supplies |
| Frequency Rating | 50/60 Hz |
| Fuse Rating | Internally Fused |
| Height | 4.85 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 0.8/1.2 Amp |
| Input Frequency | 50/60 Hertz |
| Input Voltage Range | 320 to 540 Volt AC, 450 to 760 Volt DC |
| InvoiceDescription | 240W 24V DIN T/P 380/480V IN IECEX;240W 24V PWR SPLY |
| Item Number | 00656 |
| Length | 4.36 |
| Long Description | DC POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 2.36 INCH WIDTH X 4.36 INCH DEPTH X 4.85 INCH HEIGHT SIZE; SCREW TERMINAL CONNECTION TYPE; 3 PHASE(S); UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Metal |
| Model | SDN-C |
| Mounting | DIN Rail |
| Nominal Input Voltage | 380 to 480 Volt AC |
| Noun | * |
| Number Of Phases | 3 |
| Operating Temperature | -25 to 60 Deg C |
| Output Current | 10 Amp |
| Output Power | 240 Watt |
| Output Voltage | 24 to 28 Volt DC |
| Phase | 3 |
| Product Description | 240W 24V PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 2.36 Inch Width x 4.36 Inch Depth x 4.85 Inch Height |
| Special Features | Used with SolaHD S4KC and S5K Series UPS. Terminal blocks accept Wire Sizes 24-16 AWG |
| Standard | Not Listed |
| Type | IntelliSlot Relay Card;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347200656 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Short Name | H-D |
| Voltage Rating | 380 - 400 |
| Wattage | 23.6 W |
| Width | 2.36 |
