| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN2.5-24-100P |
| Additional Information | RoHS Compliant; Maximum Inrush Current Rating 25 Amp; Overvoltage Protection 33 Volt DC; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 1.3/0.7 AMP |
| Application | Industrial Machine Control and Process, Conveying Equipment, Material Handling, Packaging Equipment;Industrial Machine Control, Process Control, Conveyor, Material Handling, Vending Machine, Packing Equipment, Amusement Park Equipment, Semiconductor Fabrication |
| Approval | UL (Canada and US), CSA, CE |
| Base Price | 0.0000 |
| Cable Size | 16 - 10 AWG Solid AWG |
| Catalog Number | SDN2.5-24-100P |
| Commerce Sector | Construction Materials |
| Commodity Code | 39620 |
| Commodity Description | Dc Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| Cooling Type | Convection |
| CountryOfOrigin | TW |
| DDCATEGORY | 2090 |
| Directory | CIS |
| Efficiency | 87.5 PCT;87.5 Percent |
| Enclosure | IP20 |
| Environmental Conditions | 90 RH Humidity Range PCT |
| Families | 2090 |
| Family Description | Dc Power Supplies |
| Frequency Rating | 47 - 63 HZ |
| Fuse Rating | Internally Fused |
| Height | 4.88 IN |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 1.3/0.7 Amp |
| Input Frequency | 47 to 63 Hertz |
| Input Voltage Range | 85 to 264 Volt AC, 90 to 375 Volt DC |
| InvoiceDescription | 60W 24V DIN P/S 115/230V IN;60W POWER SUPPLY |
| Item Number | 15318 |
| Length | 4.55 IN |
| Long Description | POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 1.97 INCH WIDTH X 4.55 INCH DEPTH X 4.88 INCH HEIGHT SIZE; SCREW TERMINAL CONNECTION TYPE; 1 PHASE(S); UL (CANADA AND US), CSA, CE APPROVAL |
| MSDS Form Number | * |
| Material | Metal Housing;Metal |
| Model | SDN-P |
| Mounting | DIN Rail |
| Nominal Input Voltage | 115/230 Volt AC |
| Noun | * |
| Number Of Phases | 1 |
| Operating Temperature | -10 to 60 Deg C |
| Output Current | 2.5 Amp |
| Output Power | 60 Watt |
| Output Voltage | 24 Volt DC |
| Phase | 1 |
| Product Description | 60W POWER SUPPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 1.97 Inch Width x 4.55 Inch Depth x 4.88 Inch Height |
| Special Features | Power Factor Correction (per EN61000-3-2), Auto Select 115/230 Vac, 50/60 Hz Input, DC OK Signal, Adjustable Voltage, Parallel Capability standard on all units, -10 DEG C to 60 DEG C operation without derating, Indefinite short circuit, overvoltage and overtemperature protection, Narrow width on rail for space critical applications, User-friendly front panel. |
| Standard | UL (CANADA AND US), UL 508, UL 60950, CUL, CSA-C22.2, CE |
| Type | SDN-P DIN Rail Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347215318 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Short Name | H-D |
| Voltage Rating | 115/230 VAC |
| Wattage | 8.6 WAT |
| Width | 1.97 IN |
