| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN4-24-100LP |
| Additional Information | RoHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 1/1.8 A |
| Application | Industrial Control, Process Control, Machine Control, Building Automation, Instrumentation;Industrial/Machine/Process Control, Amusement Park/Conveying/Packaging/Semiconductor Fabrication Equipment, Material Handling, Vending Machine, Devicenet |
| Approval | UL 508, UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 20 to 12 Solid or Stranded AWG |
| Catalog Number | SDN4-24-100LP |
| Commerce Sector | Construction Materials |
| Commodity Code | 39620 |
| Commodity Description | Dc Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| CountryOfOrigin | TW |
| DDCATEGORY | 2090 |
| Directory | CIS |
| Efficiency | 88 PCT;88 Percent |
| Enclosure | Class 1, IP20;IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2090 |
| Family Description | Dc Power Supplies |
| Frequency Rating | 47-63 Hz |
| Fuse Rating | Internally Fused |
| Height | 2.95 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 2.1/1 Amp |
| Input Frequency | 47 to 63 Hertz |
| Input Voltage Range | 85 to 132/176 to 264 Volt AC, 210 to 375 Volt DC |
| InvoiceDescription | 92W 24V DIN P/S 115/230V IN;DIN RAIL PWR SPLY |
| Item Number | 15329 |
| Length | 2.85 in |
| Long Description | DC POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 2.56 INCH WIDTH X 4.55 INCH DEPTH X 4.88 INCH HEIGHT SIZE; SCREW TERMINAL CONNECTION TYPE; 1 PHASE(S); UL 508, UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Plastic;Metal |
| Model | SDN-P |
| Mounting | DIN Rail |
| Nominal Input Voltage | 115/230 Volt AC |
| Noun | * |
| Number Of Phases | 1 |
| Operating Temperature | -10 to 60 Deg C |
| Output Current | 3.8 Amp |
| Output Power | 92 Watt |
| Output Voltage | 22.5 to 28.5 Volt DC |
| Phase | 1 |
| Product Description | DIN RAIL PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 2.56 Inch Width x 4.55 Inch Depth x 4.88 Inch Height |
| Special Features | LED Status Indication, -10 to 70 DEG C Operating Temperature, Output Voltage 24 to 28 VDC, Output Current Rating 3.8A |
| Standard | UL (CANADA AND US), UL 94, UL 508, UL 60950, CUL, CSA-C22.2, CE |
| Type | SDP Low Power DIN Rail Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347215329 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 132/264//375 VAC//VDC |
| Wattage | 13.1 W |
| Width | 3.8 in |
