| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN5-24-480C |
| Additional Information | RoHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 800m/1.2 A |
| Application | Industrial Machine Control and Process, Conveying Equipment, Material Handling, Packaging Equipment;Industrial/Machine Control, Process Control, Conveying Equipment, Material Handling, Vending Machine, Packaging Equipment, Park Equipment, Semi-Conductor Fabrication Equipment |
| Approval | UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 16 - 10 AWG Solid AWG |
| Catalog Number | SDN5-24-480C |
| Commerce Sector | Construction Materials |
| Commodity Code | 39610 |
| Commodity Description | Ac Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| Cooling Type | Convection |
| CountryOfOrigin | PH |
| DDCATEGORY | 2089 |
| Directory | CIS |
| Efficiency | 91.2 PCT;85 Percent |
| Enclosure | IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2089 |
| Family Description | Ac Power Supplies |
| Frequency Rating | 50/60 Hz |
| Fuse Rating | Internally Fused |
| Height | 4.85 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 0.5/0.7 Amp |
| Input Frequency | 50/60 Hertz |
| Input Voltage Range | 85 to 264 Volt AC, 90 to 375 Volt DC |
| InvoiceDescription | 120W 24V DIN T/P 380/480V IN IECEX;120W 24V PWR SPLY |
| Item Number | 00655 |
| Length | 4.36 in |
| Long Description | DC POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 1.97 INCH WIDTH X 4.36 INCH DEPTH X 4.85 INCH HEIGHT SIZE; SCREW TERMINAL CONNECTION TYPE; 3 PHASE(S); UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Metal |
| Model | SDN-C |
| Mounting | DIN Rail |
| Nominal Input Voltage | 380 to 480 Volt AC |
| Noun | * |
| Operating Temperature | -25 to 60 Deg C |
| Output Current | 5 Amp |
| Output Power | 120 Watt |
| Output Voltage | 24 to 28 Volt DC |
| Phase | 3 |
| Product Description | 120W 24V PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 1.97 Inch Width x 4.36 Inch Depth x 4.85 Inch Height |
| Special Features | Compact packaging to save space on the DIN rail, Visual diagnostic LEDs for input and output status at a glance, High MTBF means high reliability and long life, Higher efficiency saves energy and lowers amount of heat generated in panel, PowerBoostTM overload capability to start high inrush loads, Accepts Universal voltage 85-264 Vac, 50/60 Hz input, Active Power Factor Correction, Patented DIN rail mounting clip, User Adjustable output voltage accessible via front face, Parallel capability standard, Large, rugged, accessible screw terminals. |
| Standard | UL (CANADA AND US), UL 508, UL 60950, CUL, CSA-C22.2, CE |
| Type | SDN-C Compact DIN Rail Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347200655 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 400 VAC |
| Wattage | 23.6 W |
| Width | 2.36 in |
