| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN5-48-100P |
| Additional Information | ROHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 3.8 A |
| Application | Industrial Control, Process Control, Machine Control, Building Automation, Instrumentation;Industrial/Machine/Process Control, Amusement Park/Conveying/Packaging/Semiconductor Fabrication Equipment, Material Handling, Vending Machine, Devicenet |
| Approval | UL 508, UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 16 - 10 AWG Solid |
| Catalog Number | SDN5-48-100P |
| Commerce Sector | Construction Materials |
| Commodity Code | 39610 |
| Commodity Description | Ac Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| CountryOfOrigin | TW |
| DDCATEGORY | 2089 |
| Directory | CIS |
| Efficiency | 88;88 Percent |
| Enclosure | Nema 4X, IP66/67;IP20 |
| Environmental Conditions | 110 RH Humidity Range |
| Families | 2089 |
| Family Description | Ac Power Supplies |
| Frequency Rating | 50/60/400 Hz |
| Fuse Rating | Non-Replicable Internal Fuse |
| Height | 1.8 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 4/2.3 Ampere |
| Input Frequency | 47 to 63 Hz |
| Input Voltage Range | 85 to 132/176 to 264 VAC, 210 to 375 VDC |
| InvoiceDescription | 240W 48V DIN P/S 115/230V IN;240W 48V PWR SPLY |
| Item Number | 00191 |
| Length | 6.54 in |
| Long Description | POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 3.23 INCH W X 4.55 INCH D X 4.88 INCH H SIZE; SCREW TERMINAL CONNECTION TYPE; 1 PHASE(S); UL 508, UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Metal |
| Model | SDN-P |
| Mounting | Chassis with tabs;DIN Rail |
| Nominal Input Voltage | 115/230 VAC |
| Noun | * |
| Number Of Phases | 1 |
| Number Of Receptacles | 2 |
| Operating Temperature | -10 to 60 Deg C |
| Output Current | 5 Ampere |
| Output Power | 240 W |
| Output Voltage | (1) 48 VDC |
| Phase | 1 |
| Product Description | 240W 48V PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Receptacle Configuration | Input/3 Pole Male - Output 4 Pole Female |
| Size | 3.23 Inch W x 4.55 Inch D x 4.88 Inch H |
| Special Features | IP66/67 Versatile/NEMA 4X Rated, 24 Vdc, 115/230 Vac, 3.8A Nominal Current, Listed power supply for stand-alone applications, Can be mounted in any orientation without limitation, Universal input, High ambient temperature up to 60oC without derating, DC OK Green LED. |
| Standard | cULus Listed Ind. Control Equipment, E61379, ITE, E137632, UL 508, CSA C22.2 No. 107.1, UL 60950-1/CSA C22.2 No. 60950-1, 2nd Edition, UL Recognized Component Haz. Loc. E234790; CE Low Voltage Directive IEC/EN60950-1, 2nd Edition, RoHS Compliant |
| Type | SCP-X Extreme Environment Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347200191 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 24 VDC |
| Wattage | 95 W |
| Width | 5.33 in |
