| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDN9-12-100P |
| Additional Information | ROHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 2.3/4 A |
| Application | Industrial Machine Control and Process, Conveying Equipment, Material Handling, Packaging Equipment;Industrial/Machine/Process Control, Amusement Park/Conveying/Packaging/Semiconductor Fabrication Equipment, Material Handling, Vending Machine, Devicenet |
| Approval | UL 508, UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 16 - 10 AWG Solid AWG |
| Catalog Number | SDN9-12-100P |
| Commerce Sector | Construction Materials |
| Commodity Code | 39610 |
| Commodity Description | Ac Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| CountryOfOrigin | TW |
| DDCATEGORY | 2089 |
| Directory | CIS |
| Efficiency | 88 PCT;84 Percent |
| Enclosure | IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2089 |
| Family Description | Ac Power Supplies |
| Frequency Rating | 47-63 Hz |
| Fuse Rating | Internally Fused |
| Height | 4.88 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 2/1.5 Ampere |
| Input Frequency | 47 to 63 Hz |
| Input Voltage Range | 85 to 132/176 to 264 VAC, 210 to 375 VDC |
| InvoiceDescription | 108W 12V DIN P/S 115/230V IN;108W PWR SPLY |
| Item Number | 00192 |
| Length | 4.55 in |
| Long Description | POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; METAL MATERIAL; 2.56 INCH W X 4.55 INCH D X 4.88 INCH H SIZE; SCREW TERMINAL CONNECTION TYPE; 1 PHASE(S); UL 508, UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Metal |
| Model | SDN-P |
| Mounting | DIN Rail |
| Nominal Input Voltage | 115/230 VAC |
| Noun | * |
| Number Of Phases | 1 |
| Operating Temperature | -10 to 60 Deg C |
| Output Current | 9 Ampere |
| Output Power | 108 W |
| Output Voltage | (1) 12 VDC |
| Phase | 1 |
| Product Description | 108W PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 2.56 Inch W x 4.55 Inch D x 4.88 Inch H |
| Special Features | Power Factor Correction (per EN61000-3-2), Auto Select 115/230 Vac, 50/60 Hz Input, DC OK Signal, Adjustable Voltage, Parallel Capability standard on all units, -10 DEG C to 60 DEG C operation without derating, Indefinite short circuit, overvoltage and overtemperature protection, Narrow width on rail for space critical applications, User-friendly front panel. |
| Standard | UL (CANADA AND US), UL 508, UL 60950, CUL, CSA-C22.2, CE |
| Type | SDN-P DIN Rail Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347200192 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 115/230 VAC |
| Wattage | 28.8 W |
| Width | 3.23 in |
