| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDP2-12-100T |
| Additional Information | ROHS Compliant; Applicable Standard IEC/EN 60950-1 |
| Amperage Rating | 330m/600m A |
| Application | Industrial Control, Process Control, Machine Control, Building Automation, Instrumentation;Building Automation, Industrial/Machine/Process Control |
| Approval | UL 508, UL (Canada and US), CE |
| Base Price | 0.0000 |
| Brand Name | SolaHD |
| Cable Size | 20 to 12 Solid or Stranded AWG |
| Catalog Number | SDP2-12-100T |
| Commerce Sector | Construction Materials |
| Commodity Code | 39620 |
| Commodity Description | Dc Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Enclosed |
| CountryOfOrigin | TW |
| DDCATEGORY | 2090 |
| Directory | CIS |
| Efficiency | 80 PCT;80 Percent |
| Enclosure | Class 1, IP20;IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2090 |
| Family Description | Dc Power Supplies |
| Frequency Rating | 47-63 Hz |
| Height | 2.95 in |
| Image Location | * Image |
| Industry | ELX |
| Input Current | 0.6 Ampere at 102 VAC, 0.33 Ampere at 196 VAC |
| Input Frequency | 47 to 63 Hz |
| Input Voltage Range | 85 to 264 VAC, 90 to 375 VDC |
| InvoiceDescription | 30W 12V DIN PLASTIC 115/230VIN;30W 12V PWR SPLY |
| Item Number | 15165 |
| Length | 1.77 in |
| Long Description | DC POWER SUPPLY, ADJUSTABLE SINGLE DC OUTPUT TYPE; PLASTIC MATERIAL; 1.77 INCH W X 3.58 INCH D X 2.95 INCH H SIZE; SCREW TERMINAL CONNECTION TYPE; UL 508, UL (CANADA AND US), CE APPROVAL |
| MSDS Form Number | * |
| Material | Plastic |
| Model | SDP |
| Mounting | DIN Rail |
| Noun | * |
| Operating Temperature | -10 to 60 Deg C |
| Output Current | 3 Ampere at 10 VDC, 2.5 Ampere at 12 VDC |
| Output Power | 30 W |
| Output Voltage | 9.9 to 12.1 VDC |
| Product Description | 30W 12V PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 1.77 Inch W x 3.58 Inch D x 2.95 Inch H |
| Special Features | LED Status Indication, -10 to 70 DEG C Operating Temperature, Output Voltage 5 to 6 VDC, Output Current Rating 5A |
| Standard | UL (CANADA AND US), UL 94, UL 508, UL 60950, CUL, CSA-C22.2, CE |
| Type | SDP Low Power DIN Rail Series;Adjustable Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347215165 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 264//375 VAC//VDC |
| Width | 3.58 in |
