| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SDP4-24-100RT |
| Additional Information | RoHS Compliant; Overall Size 2.95 Inch Height x 3.8 Inch Depth |
| Amperage Rating | 30 AMPS |
| Application | PADS provide output distribution, input connection and a rotary maintenance bypass switch. Field installed by the customer to allow the UPS to be removed without interrupting power to the load.;Industrial Control, Machine Control, Building Automation, Instrumentation |
| Approval | UL (Canada and US), CUL (Canada and US), CE, NEC Class 2 |
| Base Price | 0.0000 |
| Cable Size | 20 to 12 Solid or Stranded |
| Catalog Number | SDP4-24-100RT |
| Commerce Sector | Construction Materials |
| Commodity Code | 39620 |
| Commodity Description | Dc Power Supplies |
| Conductor Size | 20 to 12 AWG |
| CountryOfOrigin | TW |
| Current Rating | 3.8 Amp |
| DDCATEGORY | 2090 |
| Directory | CIS |
| Efficiency | 88 |
| Enclosure | Class 1, IP20 |
| Environmental Conditions | 90 RH Humidity Range |
| Families | 2090 |
| Family Description | Dc Power Supplies |
| Frequency Rating | 47/63 |
| Height | 2.95 |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 100W 24V DIN PLASTIC 115/230V;100W 24V PWR SPLY |
| Item Number | 15153 |
| Length | 2.85;2.85 Inch |
| Long Description | DC POWER SUPPLY, 2.85 INCH; UL (CANADA AND US), CUL (CANADA AND US), CE, NEC CLASS 2 APPROVAL; INDUSTRIAL CONTROL, MACHINE CONTROL, BUILDING AUTOMATION, INSTRUMENTATION APPLICATION; 24 TO 28 VOLT DC VOLTAGE RATING; 3.8 AMP CURRENT RATING |
| MSDS Form Number | * |
| Material | Molded Plastic |
| Model | SDP |
| Mounting | DIN Rail |
| Noun | * |
| Product Description | 100W 24V PWR SPLY |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Special Features | Used with S4K2U (2000 VA Models) |
| Standard | Not Listed |
| Type | Power A/C Distribution (PAD) |
| UNSPSC | 39121004 |
| UPC | 78347215153 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 120 VAC;24 to 28 Volt DC |
| Width | 3.8 |
