| Manufacturer Name | SOLA/HEVI-DUTY ELEC |
| MfgPartNo | SLS-05-030-1T |
| Additional Information | Response Time 50 Millisecond at 50 Percent Load Changes; Ripple 3 Millivolt (Maximum Peak-to-Peak) |
| Amperage Rating | 5 V @ 3 A |
| Application | Industrial Control Circuits and Components, Instrumentation, Drives, CNC Machinery, Equipment for food industry, Microprocessor Circuits, Analog Circuits, Noise sensitive Circuitry and Sensors;Analog Circuit, CNC Machinery, Drives, Equipment for Food Industry, Instrumentation, Industrial Control Circuit and Component, Microprocessor Circuit, Noise Sensitive Circuitry and Sensor |
| Approval | UL (Canada and US), CSA C22.2, CE |
| Base Price | 0.0000 |
| Catalog Number | SLS-05-030-1T |
| Commerce Sector | Construction Materials |
| Commodity Code | 39620 |
| Commodity Description | Dc Power Supplies |
| Connection Type | Screw Terminal |
| Construction | Open |
| Cooling Type | Forced Air |
| CountryOfOrigin | VN |
| DDCATEGORY | 2090 |
| Directory | CIS |
| Enclosure | Case B1 |
| Families | 2090 |
| Family Description | Dc Power Supplies |
| Frequency Rating | 47 to 63 HZ |
| Height | 5.62 IN |
| Image Location | * Image |
| Industry | ELX |
| Input Frequency | 47 to 63 Hz |
| Input Voltage Range | 100/120/220/230/240 VAC (User Selectable) |
| InvoiceDescription | SINGLE 5V 3A OVP LINEAR PS;OPEN FRAME LINEAR |
| Item Number | 60067 |
| Length | 4.87 IN |
| Line Regulation | 0.05 Percent for 10 Percent Change |
| Load Regulation | 0.05 Percent for 50 Percent Change |
| Long Description | DC LINEAR POWER SUPPLY, SINGLE DC OUTPUT TYPE; 4.843 INCH L X 3.992 INCH W X 1.62 INCH H SIZE; SCREW TERMINAL CONNECTION TYPE; UL (CANADA AND US), CSA C22.2, CE APPROVAL |
| MSDS Form Number | * |
| Model | SLS |
| Mounting | DIN Rail |
| Noun | * |
| Operating Temperature | 0 to 50 Deg C |
| Output Current | 3 Ampere at 5 VDC |
| Output Power | 15 to 244 W |
| Output Voltage | (1) 5 VDC |
| Product Description | OPEN FRAME LINEAR |
| Product Keywords | WEBREADY |
| Product Name | Power supply units |
| ProductLine | H-D |
| Size | 4.843 Inch L x 3.992 Inch W x 1.62 Inch H |
| Special Features | Easy-to-install screw terminal connections, Cover options, Industry standard footprint, Universal input and approvals (115/230 Vac), Low noise, extremely quiet DC output. For noise sensitive or analog circuitry. Fast transient response. Ideal for test applications. Built-in OVP on 5 V models and optional on 12, 15 and 24 V models. Automatic resetting overload protection. Short circuit protected. |
| Standard | UL Recognized Component, ITE, UL 60950-1, CSA Certified, ITE CSA C22.2 CSA 60950-1, CE, IEC60950-1 |
| Type | Silver Line Series - Single & Multi-Output Linears;Single DC Output |
| UNSPSC | 39121004 |
| UPC | 78347260067 |
| Vendor Name | SOLA/HEVI-DUTY ELEC |
| Vendor Number | 783472 |
| Vendor Short Name | H-D |
| Voltage Rating | 100, 120, 220, 230, 240 Selectable VAC |
| Width | 2.5 IN |
