HOFF A24HS2108LP

Encl Disc Clmp Typ4 Gy MS 24x21x8

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
Encl Disc Clmp Typ4 Gy MS 24x21x8

Mouse over image to zoom, click to enlarge

Description:
Encl Disc Clmp Typ4 Gy MS 24x21x8

UPC:  78351020110

Part Number: A24HS2108LP

UNSPSC: 39121324

Status:  UNKNOWN

Retail Price:  $1,093.00 / EA
Your Price:  $1,016.49 / EA


Quantity  EA

Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo A24HS2108LP
Additional Information RoHS/Reach Compliant; Applicable Standard IEC 60529; Includes Thermoplastic Data Pocket, Installation Instruction
Application Arc Flash Safety;Controls and Drives;Power Distribution
Approval UL 508A, CUL, CSA C22.2
Back Panel A24P20, A24P20G
Base Price 0.0000
Catalog Number A24HS2108LP
Clamp Quantity 5
Color Gray;ANSI 61 Gray
Color Code ANSI 61
Commerce Sector Construction Materials
Commodity Code 36160
Commodity Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Conductive Panel A24P20G
CountryOfOrigin US
Cover Type Continuous Hinged, Hinge Pin, (5) Clamp, Bracket, Gasketed
DDCATEGORY 1962
Data Pocket Size Imperial 6.00 x 6.00 in
Depth 8;8 Inch
Depth Imperial 8 in
Depth Metric 203 mm
Directory CIS
Enclosure NEMA 3/4/12/13, IP66
Families 1962
Family Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Finish Powder Coated;Polyester Powder Painted
Height 24;24 Inch
Height Imperial 24 in
Height Metric 610 mm
IP Rating IP66
Image Location * Image
Industry ELX
InvoiceDescription Disconnect Encl. 24.00x21.38x8;NEMA4 DISCONN ENC
Item Number 20110
Long Description WALL MOUNT DISCONNECT ENCLOSURE, 1-DOOR, FLANGE MOUNT CIRCUIT BREAKER/DISCONNECT SWITCH TYPE; MILD STEEL MATERIAL; POLYESTER POWDER PAINTED FINISH; ANSI 61 GRAY COLOR; 21.38 INCH; 24 INCH; 8 INCH; UL 508A, CUL, CSA C22.2 APPROVAL; WALL MOUNTING
MSDS Form Number *
Material Steel;Mild Steel
Material Specification 14 Gauge
Model A19
Modification Services Yes
Mounting Wall
NEMA Rating 4
Noun *
Panel A24P20
Panel Size Imperial 21.00 x 17.00 in
Panel Size Metric 533 x 432 mm
Product Description Encl Disc Clmp Typ4 Gy MS 24x21x8
Product Keywords WEBREADY
Product Name Electrical general purpose enclosure
ProductLine HOFF
Protection Rating NEMA Type 4
Size 24.00x21.38x8.00 in
Thickness Imperial 14 ga
Type Mild Steel Wall Mounted Industrial Disconnect Enclosures;1-Door, Flange Mount Circuit Breaker/Disconnect Switch
Type Number Type 4
UNSPSC 39121324
UPC 78351020110
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Weight Imperial 50 lb
Width 21.38;21.38 Inch
Width Imperial 21.38 in
Width Metric 543 mm
