HOFF CR290416G002

115V,50/60Hz,13.5/13.5A,4000BT

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
115V,50/60Hz,13.5/13.5A,4000BT

Mouse over image to zoom, click to enlarge

Description:
115V,50/60Hz,13.5/13.5A,4000BT

UPC:  78351075610

Part Number: CR290416G002

UNSPSC: 40101701

Status:  UNKNOWN

Retail Price:  $5,884.00 / EA
Your Price:  $4,883.72 / EA


Quantity  EA

Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo CR290416G002
Additional Information RoHS Compliant; Refrigerant Type R134A; Sound Level 62 Decibel; Application Indoor
Amperage Rating 12.1 A
Application Controls and Drives;Corrosive Environments;Power Distribution
Approval UL, CUL, CE, EAC
BTU Rating 4,000
Base Price 0.0000
Brand Name ProAir
Catalog Number CR290416G002
Color Gray
Color Code RAL 7035
Commerce Sector Construction Materials
Commodity Code 36810
Commodity Description Enclosure Air Conditioners
Connection Type 6 Foot Cord with NEMA 5-20 Plug
Cooling Capacity 3500/4000 BTU/Hour
CountryOfOrigin US
Current Rating 12.7/12.1 Amp
DDCATEGORY 1986
Depth Imperial 8.63 in
Depth Metric 219 mm
Directory CIS
Enclosure NEMA 3R/12
Enclosure Finish RAL 7035 Light Gray Semi-Textured Powder Coated Paint
Enclosure Material Mild Steel Sheet Metal
Families 1986
Family Description Enclosure Air Conditioners
Finish Powder Coated
Frequency Rating 50/60 Hertz
Frequency Rating Maximum 60 Hz
Frequency Rating Minimum 50 Hz
Height Imperial 29.5 in
Height Metric 749 mm
Housing Material Mild Steel
Image Location * Image
Industry ELX
Installation Enclosure
InvoiceDescription 115V,50/60Hz,13.5/13.5A,4000BT;3500/4000BTU A/C
Item Number 75610
Long Description AIR CONDITIONER, 15.75 INCH WIDTH X 8.63 INCH DEPTH X 29.5 INCH HEIGHT SIZE; 50/60 HERTZ FREQUENCY RATING; 6 FOOT CORD WITH NEMA 5-20 PLUG CONNECTION TYPE; ENCLOSURE INSTALLATION; MILD STEEL SHEET METAL ENCLOSURE MATERIAL; 1 PHASE(S)
MSDS Form Number *
Material Mild Steel
Max Current 12.1 A
Mechanical Advantage Stainless steel optional
Model Surface Mounted;CR29, MCL
NEMA Rating 12 Indoor, dust-resistant
Nominal Capacity Btu H 4,000 Btu/h
Nominal Capacity Watts 1,172 W
Nominal Voltage 115 V
Noun *
Number Of Phases 1
Operating Temperature 131 deg F;-40 to 131 Degree F
Operating Temperature Imperial -40-131 F
Operating Temperature Metric -40-55 C
Phase 1
Power 1172 W
Power Rating 1116/1253 Watt
Product Description 115V,50/60Hz,13.5/13.5A,4000BT
Product Family ProAir
Product Keywords WEBREADY
Product Name Air conditioners
ProductLine HOFF
Protection Rating NEMA Type 12
Remote Access Control No
Size 15.75 Inch Width x 8.63 Inch Depth x 29.5 Inch Height
Temperature Control Type Thermostat
Thickness Imperial 18 ga
Type Air Conditioners
UNSPSC 40101701
UPC 78351075610
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Voltage AC 100-120 V
Voltage Rating 115 VAC;115 Volt AC
WEIGHT 118 Pound
Weight Imperial 99 lb
Weight Metric 54 kg|
